Tuning
Access Set Up Return to Operation Next menu Next parameter Next value Access Tuning Return to Operation
+
FAST MENU
DISPLAY
+
MENU MENU
▲ ▼
MENU DISPLAYFAST
21. PROP. BND.:X
Defines the proportional band for PID set X.
R 0.1 to 999.0%
D 50.0%
22. RESET:X
Defines the integral time for PID set X.
R 1 to 9999 seconds (increments of 1)
D 20 seconds
23. RATE:X
Defines the derivative time for PID set X.
R 0 to 600 seconds
D 1 seconds
24. MAN. RST.:X (or LOADLINE:X)
Defines the manual reset (or load line) for PID set X.
R 0 to 100%
D 0%
25. TRIP:X
This defines the value that triggers a change to the Xth set of PID values.
R The process variable range
D Dependent on the process variable range
MAN.RST.:X
0
TRIP:X
(D)
RATE:X
1
RESET:X
(D)
PROP.BND.:X
(D)
