Moore Industries THZ3 - Page 111

www.miinet.comMoore Industries-International, Inc.
- 111 -
User’s Manual
238-741-00K
May 2019
Programmable Smart HART Temperature Transmitter
THZ
3
/ TDZ
3
Configure Custom Name– The Configure Custom Name allows you to enable and assign a
custom label for your choice. Dynamic Variables cannot have a custom name. However
when the underlying Device Variable’s name is shown, the custom name is shown instead.
See Figure 5.46 .
Note: Both the Custom EGU and Custom Name are limited to 5 alphanumeric characters.
Legal characters are:
A-Z (caps only)
0-9
% ` ( ) * + , - / < = > ? @ [ \ ] ^ _
HART Settings:
The HART Settings menu provides access to Basic Setup HART settings. See basic Setup
for further clarication. Additionally this menu allows for conguration of 3 unique HART Burst
Messages. Refer to HART Broadcast messaging at the beginning of Section 4 for clarication on
settings and functions.
HART Burst Message 1-3– Here you can enable or disable and configure HART Burst
messages 1-3. See Figure 5.47 for clarification.
SECTION 5
Figure 5.46. THZ
3
/ TDZ
3
Configure Custom Name in Display Menu for Advanced Setup
Figure 5.47. THZ
3
/ TDZ
3
HART Burst Messages 1-3 in HART Settings Menu for Advanced Setup
