Custom Calibration:
The Advanced Setup for the Custom Calibration menu contains similar features as the Basic
Setup with added feature of Sensor 1/2 Corrosion.
Programmable Smart HART Temperature Transmitter
THZ
3
/ TDZ
3
SECTION 5
Sensor 1 and Sensor 2 Corrosion
The Sensor 1/2 menu is only available when Sensor 1 or 2 Corrosion are enabled in the
I nput/Congure Sensor 1 or 2 Menu in the Advanced Setup .
This menu allows you to capture the nominal sensor resistance value, you can also check the
current resistance value and corrosion the status.
For a more detailed explanation refer to Corrosion Detection in Section 1.
Figure 5.48. THZ
3
/ TDZ
3
Custom Calibration Menu - Sensor 1 Corrosion and Sensor 2 Corrosion
