SECTION 6
TDZ3 Display Condition
ERROR FEND Communications with the front end have failed
ERROR NVMEM Failure to restore configuration from non-volatile storage
ITRNL INVLD Stored Factory information is invalid
ERROR CONFIG There is one or more configuration error
CORRn
WARN/ERROR
Corrosion sensor n is indicating a warning / error condition
RA n WARN/ERROR Range Alarm n is indicaing a warning / error condition
OUT SATLO / SATHI The Loop Current has reached the configured Under/ Over Range Value
and is being limited there.
CAL C ERROR Configuration error detection when calibration attempted
CAL D ERROR An input error was detected during calibration
Table 6.2. TDZ
3
or THZ
3
Display Errors- System
One or more diagnostic has failed
ERROR COP Unit was reset due to the watchdog
The RAM Test has detected a failure
ERROR ROM The ROM Diagnostic has detected a failure
ERROR ALU The CPU's ALU (Arithmetic Logic Unit) Diagnostic has detected a failure
ERROR I/O The CPU's IO Diagnostic has detected a failure
ERROR REG The CPU's Register Diagnostic has detected a failure
ERROR SQMON The sequence monitor diagnostic has detected a failure
ERROR STACK The Stack Monitor Diagnostic has detected a failure
ERROR ICUR The Injection Current Diagnostic has detected a failure
ERROR SWARE General Software Fault
TDZ3 Display Condition
Table 6.3. TDZ
3
or THZ
3
Display Errors- Diagnostic Fails
