User’s Manual
238-741-00K
May 2019
Programmable Smart HART Temperature Transmitter
THZ
3
/ TDZ
3
SECTION 4
Device Setup Menu
The Device Setup menu allows you to access the following menus: Process Variable, Setup,
Custom Calibration and Review refer to Figure 4.2.
Figure 4.2. TDZ
3
or THZ
3
Device Setup menu
Figure 4.3. TDZ
3
or THZ
3
Process Variable menu
Process Variable Menu:
The Process Variable menu displays the present values of parameters listed on the
Communicator display which include the selected EGU, PV, PV Quality, PV Loop current,
PV is, PV Damping, PV % Range, Dynamic Variables and Device Variables.
Dynamic Variables– The Dynamic Variables menu displays the present Dynamic
Variables parameter values.
Device Variables– The Device Variables menu displays the present Device Variables
parameter values. If any Device Variable quality is not good, this will show its data quality
flag instead of its value.
Online Menu
Mode l
Device Setup
PV is
PV Quality
PV
PV Loop Current
PV LRV
PV URV
SV
TV
QV
Range Alarm
Status*
Process
Vari ables
Setup
Custom
Calibraon
Review
See Figure 4.3
*Available only when
“Advance Sengs” is
enabled.
See Figure 4.4
See Figure 4.14
See Figure 4.17
Online Menu
Mode l
Device Setup
PV is
PV Quality
PV
PV Loop Current
PV LRV
PV URV
SV
TV
QV
Range Alarm
Status*
Process
Variables
Setup
Custom
Calibraon
Review
PV
PV Quality
PV Loop Current
PV is
PV Damping
PV % range
Dynami c
Variables
Device
Variables
PV
PV Quality
PV is
SV
SV Quality
SV is
TV
TV Quality
TV is
QV
QV Quality
QV is
Refr esh Device Vars
RJC Temp
Sensor 1
Sensor 2
Backup 1-2
Backup 2-1
Average
Differen al 1-2
Differen al 2-1
Absolute Differenal
Low Select
High Select
*Ava ilable only when
“Advance Sengs” is
enabled.
