Moore Industries THZ3 - Page 79

www.miinet.comMoore Industries-International, Inc.
- 79 -
User’s Manual
238-741-00K
May 2019
Programmable Smart HART Temperature Transmitter
THZ
3
/ TDZ
3
SECTION 5
Figure 5.3. THZ
3
DIN hook-up diagram for HART or MISP DTM configurations.
SMART HART
TEMPERATURE
TRANSMITTER
DUAL SENSOR
PC
HART Modem
OR
MISP
Moore Indusries
P/N: 804-030-26
To USB
Port of PC
To COM Port
of THZ3
+
–
12-24Vdc
Power
Supply
Current Meter
Load= 250 ohms
–
+
Voltage
Source
–
+
HART Held
Communicator
or
HART Modem
connects to
Serial/USB
COM Port of PC
