SECTION 5
THZ3/TDZ3 DTM Parameter Reference guide
The following provides a comprehensive list of DTM conguration menus and options which can
be used as a quick reference guide to identify the di󰀨erent conguration capabilities and locate
them in the menu system. For more information on the specic features please refer to the
Conguration Overview and the specic menu descriptions.
Note:
* Is used to identify advanced features which are only accessible using Advanced Setup
menus in the DTM.
THZ
3
/TDZ
3
Parameter
Input
Congure Sensor
*RJC Temp – change engineering units (EGU)
Sensor 1/2
-Input & Type (eg. Thermocouple TypeK, 4W RTD Pt3850 100ohm etc.)
-EGU (engineering units)
-Broken Wire detection & hold o󰀨
-Running Average lter
-2-Wire o󰀨set (2W RTD/resistance only)
-*Corrosion detection (enable, base, warning and failure settings)
-Serial Number
-Filter – 50Hz or 60Hz input lter to reduce mains induced noise
*Sensor 1/2 Scaling
*Sensor 1/2 Custom Curve enable & selection
Ranging & Mapping
Primary Variable
-PV (Analog Output Source) selection
-Smart Range –sets the PV Zero and Full values to AO 0-100%
-PV Damping – set delay in the response to stop input noise from generating output errors
SV, TV & QV Mapping- assigns the Device Variables (eg. SEN1, BU1-2)
*Congure Dual Input
*Scaling settings and Custom Curve selection for all the calculated Device Variables
*System Conguration
*High Availability (Input Quality Alarms) setup
Allow Measurement Out of Conformance Range
Allow Limited
Allow Dropping
*Custom Curves – import/input 1-4 custom curves
*Range Alarms – congure up to 4 range alarms
