User’s Manual
238-741-00K
May 2019
Programmable Smart HART Temperature Transmitter
THZ
3
/ TDZ
3
SECTION 5
Analog Output
PV input range (display only)
AO Zero & Full Values
AO Under Range & Over Range Values
AO Fail Mode (High, Low, Hold Last, Fail to Value)
Display (TDZ
3
only)
Select Dynamic & Device Variables to be displayed
Number of Decimal Places
*Congure Custom EGU & Custom Name
HART Settings
Allows conguration of HART parameters:
Polling Address
Number of HART response preamble characters
Tag, Long Tag, Descriptor, Message, Final assembly number
Programmed Date, Device id, Hardware revision, HART Revision, Firmware revision (Read only)
*Burst Conguration - can be congured to send out up to 3 burst messages
Custom Calibration
Input (PV) Capture - match the device input and output zero and full scale to a known value.
Sensor 1/2 Trim
Analog Output Loop Test & Trim
Input Simulation - Clear or Set a simulated Input.
*Sensor 1/2 Corrosion Detection base value capture and monitor
