SECTION 3 - TECHNICAL DATA
Note. Gas consumption is calculated using a
caloricvalueof95.65MJ/m
3
gross or 88.0
MJ/m
3
nett
To obtain the gas consumption at a different
caloricvalue:
a. For l/s-dividethegrossheatinput(kW)by
thegrossC.V.ofthegas(MJ/m
3
)
b. For m
3
/h -multiplyl/sby3.6.
Key to symbols
C
13
C
33
= A room sealed appliance designed for connection via ducts to a horizontal
or vertical terminal, which admits fresh air to the burner and discharges
the products of combustion to the outside through orices which, in this
case, are concentric. The fan is upstream of the combustion chamber.
I
3P
= An appliance designed for use on 3rd Family gas, Group P only.
II
2H3P
= Appliances capable of using gases of Group H and gases of Group P.
* The value is used in the UK Government’s Standard Assessment Procedure (SAP) for energy rating of dwellings. The test data from
which it has been calculated have been certied by a notied body.
Table 2 - Performance Data - Central Heating
Table 1 General Data
Table 3 - Performance Data - Domestic Hot Water
Maximum DHW Input : 24 30
Nett CV kW 24.3 30.4
Gross CV kW 27 33.7
Gas Consumption m
3
/h 1.00 1.25
kg/hr 1.83 2.26
Maximum DHW Output kW 24.2 30.3
DHW Flow Rate l/min 9.9 12.4
at 35°C temp. rise. gpm 2.2 2.8
DHW Specic Rate l/min 11.5 14.5
gpm 2.5 3.2
Morco GB IV 24 30
Gas Supply** II
2H3P
- G31 - 37mbar (I
3P
G31 - 30mbar DE/NL) (I
3P
G31 - 37mbar BE/NL/PL)
Gas Supply Connection 15mm copper compression
Injector Size mm 3.75 3.75
Inlet Connection Domestic Hot Water G ½
Outlet Connection Domestic Hot Water G ½
Flow Connection Central Heating G ¾
Return Connection Central Heating G ¾
Flue Terminal Diameter mm 100
Average Flue Temp-Mass Flow Rate DHW 63ºC - 11 g/s 68ºC - 13 g/s
CO
2
Content (± 0.7) Max. DHW 11.0 % 11.1 %
Min. CH/DHW 10.0 % 10.0 %
Maximum Working Pressure (Sealed Systems) bar (lb/in
2
) 2.5 (36.3)
Maximum Domestic Hot Water Inlet Pressure bar (lb/in
2
) (kPa) 10.0 (145) (1000)
Minimum Domestic Hot Water Inlet Pressure* bar (lb/in
2
) (kPa) 0.8 (11.6) (80) 1.3 (18.9) (130)
Electrical Supply 230 V - 50 Hz.
Power Consumption W 79 75
Fuse Rating External : 3A Internal : T4H HRC L250 V
Water Content Central Heating litre (gal) 1.2 (0.26)
Domestic Hot Water litre (gal) litre (gal) 0.5 (0.11)
Packaged Weight kg 32.9 32.9
Maximum Installation Weight kg 30 30
Boiler Casing Size Height mm 700
Width mm 395
Depth mm 285
Max. Min.
Boiler Input : 24 30 24 30
Boiler Input ‘Q’ Nett CV kW 24.3 8 8
Gross CV
kW
26.4 8.7 8.7
Gas Consumption m
3
/h 1.0 0.329 0.329
kg/hr 1.83 0.600 0.600
Boiler Output : 24 30 24 30
Non Condensing 70° C
Mean Water Temp.
kW
24.2 8 8
Condensing 40° C
Mean Water Temp.
kW
25.6 8.5 8.5
Seasonal efciency* SEDBUK
2005
24kW = 91.0 30kW = 91.1
Seasonal efciency* SEDBUK
2009
24kW = 89.0 30kW = 89.0
NOx Classication CLASS 6
3 TECHNICAL DATA
3.1 DATA TABLES
*Requiredformaximumowrate.Boileroperatesdownto2l/minDHWdelivery
**Refer to Destination Countries Section
