5. Clearing a Paper Jam
44
Open the top cover.
Lift up both upper feed belts (A).
Note
Press the green-labelled latches (B) to release.
Remove the jams.
Place the upper feed belts in normal position.
Close the top cover.
Inside the SquareFolder
Exit Area
Open the top cover (A).
Lift up the Belt Stacker Cover (B).
Remove the jam.
Place the Belt Stacker Cover in normal position.
Close the top cover.
A
A
Clearing a Paper Jam
SquareFolder
B
B
