Morgana BM 2000 - Access to Machine

51
7. General Remarks
Access to Machine
Place the machine near the power source, providing clearance as shown.
1. Left: more than 400 mm / 15 3/4”
2. Front: more than 555 mm / 21 7/8”
(3). Right: more than 400 mm / 15 3/4” (for stand alone installation only)
2
(3)
1
