Instruction Manual
MORSØ Mitring Machine
Model F
42
Adjustment of the Return Springs
The return springs (42) which return the knife block (4) to the topmost position are attached
to the spring anchors (43) located in the bottom holes in the sides of the main frame.
If the return action is not quick enough or if the springs loose some of their tension after a
while, the spring anchors (43) can be relocated up to the next hole in the frame.
(N.B. Do not confuse this effect with the lack of lubrication of the vertical knife block slides
(10).)
1. A piece of wood should be placed under the knives on the table (2) in order to keep the
knife block (4) in the up position.
2. Loosen nut (44)
Only on the side which you are adjusting.
3. Remove the outer washer (45).
4. By means of a suitable tool the spring (42) is stretched upwards so that the spring anchor
(43) can be moved to the next hole.
5. Replace the washer (45) and nut (44) and tighten.
6. Adopt the same procedure on the other side.
Service F-5
