MoTeC Appendices 49
Pin Name Function
Auxiliary Outputs
5 AUX1 Auxiliary Output 1
6 AUX2 Auxiliary Output 2
7 AUX3 Auxiliary Output 3
8 AUX4 Auxiliary Output 4
8 V Sensor
13 8V Sensor 8 V
5 V Sensor
14 5V Sensor 5 V
0 V Sensor
37 0V Sensor 0 V
CAN Interface
36 CAN0H CAN 0 High
35 CAN0L CAN 0 Low
30 CAN1H CAN 1 High
29 CAN1L CAN 1 Low
Ethernet
9 E-RX- Ethernet Receive -
24 E-RX+ Ethernet Receive +
10 E-TX- Ethernet Transmit -
25 E-TX+ Ethernet Transmit +
RS232
34 RX RS232 Input
33 TX RS232 Output
