Wiring
This section provides reference material about the Dash Logger's connector
and wiring requirements.
Connector
SDL3 connector
37 pin Autosport connector
Mating connector
#68089
Wire Specification
Wire
Wire to suit Dash Logger connector: 22# Tefzel, Mil Spec : M22759/16-22
M22759/16 Wire Ratings (for various wire gauges)
Insulation Material: Tefzel
Conductor: Tin Plated Copper
Voltage Rating: 600 V
Maximum Temperature: 150 °C
Wire Gauge
[AWG]
Cross
Sectional Area
[mm2]
Max Current
at 100 °C
Ambient [A]
Resistance
[ohm/m]
Resistance
[ohm / 1000 ft]
22 0.38 5 0.045 14.0
20 0.61 6 0.028 8.5
18 0.96 9 0.018 5.5
16 1.2 12 0.014 4.3
14 1.9 18 0.009 2.7
12 3.0 24 0.006 1.8
Crimp Tool
Crimp Tool: M22520/2-01
Positioner for Crimp Tool: M22520/2-07
Crimp Contacts are type 22D (needed to set the crimp tool correctly)
