48 Appendices
SDL3 Pin List by Function
Pin Name Function
Battery Power
4 BAT- Battery Negative
3 BAT+ Battery Positive
Analogue Voltage Inputs
15 AV1 Analogue Voltage Input 1
16 AV2 Analogue Voltage Input 2
17 AV3 Analogue Voltage Input 3
18 AV4 Analogue Voltage Input 4
1 AV5 Analogue Voltage Input 5
2 AV6 Analogue Voltage Input 6
19 AV7 Analogue Voltage Input 7
20 AV8 Analogue Voltage Input 8
Analogue Temp Inputs
21 AT1 Analogue Temp Input 1
22 AT2 Analogue Temp Input 2
31 AT3 Analogue Temp Input 3
32 AT4 Analogue Temp Input 4
Digital Inputs
27 DIG1 Digital Input 1
28 DIG2 Digital Input 2
Speed Inputs
23 SPD1 Speed Input 1
26 SPD2 Speed Input 2
11 SPD3 Speed Input 3
12 SPD4 Speed Input 4
