Why is my Motec MD3071A Automobile Accessories system not starting?
The Motec Automobile Accessories system might not start due to several reasons: the power supply may not be turned on (turn it on and check/replace the fuse if needed), the power supply cable could be defective (replace the cable), or the video control unit itself might be defective (replace the video control unit).
What to do if the monitor displays a blue screen with Motec MD3071A?
A blue monitor screen with Motec Automobile Accessories typically indicates no video signal. Check the cable connection between the video control unit and the monitor, and replace any defective cables. Ensure the connector is tightly fitted by tightening the union nuts of the connector on the video control unit hand-tight and latching the flap into place on the side of the monitor. If this doesn't resolve the issue, the video control unit might be defective and needs replacement.
What to do if the monitor display is not available and the green LEDs on the Motec MD3071A Automobile Accessories video control unit are lit?
If the green LEDs on the video control unit of your Motec Automobile Accessories are lit but the monitor display is unavailable, it could be due to loose connectors or a defective monitor cable (check the monitor cable and connector for damage or tight fit), a defective monitor (check monitor for function, replace if necessary), or a defective video control unit (replace video control unit).
What to do if the monitor display is not available and the green LEDs on the Motec MD3071A video control unit are not lit?
If the monitor display is not available and the green LEDs on the video control unit of your Motec Automobile Accessories are not lit, the video control unit might not be activated. Activate the power supply.
Why does the entire image disappear temporarily on my Motec MD3071A Automobile Accessories?
A temporary disappearance of the entire image on your Motec Automobile Accessories likely results from a loose contact or defective cable. Check the cable connection between the video control unit and the monitor, and replace defective cables. Also, check the connector for a tight fit, tighten the union nuts of the connector on the video control unit hand-tight, and latch the flap into place on the side of the monitor.
Why is part of the image blue on my Motec MD3071A Automobile Accessories display?
If part of the image is blue on your Motec Automobile Accessories, the video signal of the affected camera might not be available on the video control unit (check the cable connection between the video control unit and the camera, replace defective cables, and check the plug connector for a tight fit) or the camera itself may be defective (replace the camera).
Why is the image blurred on my Motec Automobile Accessories?
A blurred image on your Motec Automobile Accessories could be due to a protective film that hasn't been removed from the monitor or cameras (remove protective film) or because the cameras are dirty (carefully clean the cameras with plenty of water and a soft cloth, being cautious to avoid scratching).
Why is part of the image shaking in the top view on my Motec MD3071A?
If part of the image is shaking in the top view on your Motec Automobile Accessories, the attachment of the affected camera might be loose. Check the camera bracket for a tight fit.
Why is the top view partially shifted on my Motec MD3071A Automobile Accessories?
If the top view has partially shifted on your Motec Automobile Accessories, the camera(s) might not be correctly aligned, or the adjustment is off. Re-align the camera(s) and re-calibrate the system.
Why are objects in the detection range of the ultrasonic sensors not shown on Motec Automobile Accessories?
Here are a few reasons why objects in the detection range of the ultrasonic sensors might not be displayed on your Motec Automobile Accessories: * Incorrect alignment of the sensors (check and correct alignment). * Evaluation unit of MVCU1300 defective. * Cable connection or sensor defective (check cable connection and plug connector; replace defective sensors with identical types). * No CAN connection between MVCU1300 and video control unit.
General| Category | Automobile Accessories |
|---|---|
| Display Size | 7 inch |
| Protection Rating | IP65 |
| Communication Interface | CAN, RS232 |
| Operating Temperature | -20°C to +70°C |
