Motec MD3071A - Ultrasound Sensors

26
Ultrasound sensors
Behaviour/malfunction
Possible cause
Corrective action
Objects in the detection
range of the ultrasonic
sensors are not shown
Incorrect alignment of the sensors.
Check and correct alignment.
Evaluationn unit of MVCU1300
defective.
Ask a certified service partner to
check the system, and if necessary,
have it repaired.
Cable connection or sensor
defective.
Check cable connection and plug
connector.
Check sensors, replace defective
sensors with identical types.
No CAN connection between
MVCU1300 and video control unit.
Ask a certified service partner to
check the system, and if necessary,
have it repaired.
