Motec MD3071A - Monitor

17
Monitor
Fig.
5
: MD3071A
Fig.
6
: MD3071A-V
The 7'' monitor displays the image calculated by the video
control unit.
Depending on the system configuration, the monitor is
available in two models:
System
Monitor
360° or 270°
system
MD3071A-V
Vertical monitor alignment (portrait
format)
270° system
MD3071A
Horizontal monitor alignment
(landscape format)
