2 Introduction
Logging and Analysis
• Optional internal data logging of 16 MB or 120 MB
• Fast download via Ethernet
• Accommodating over 300 channels derived from a mixture of analogue
and digital inputs, RS232 and CAN data channels
• Configurable to use sensors from some existing engine management
systems
• Data analysis with i2 Standard or optional i2 Pro software
Display
• Customisable screen layout, measurement units and warnings
• Configurable curved bar graph can display any channel with optional
peak, hold and shift markers
• 48 user-defined alarms, for example Low Oil Pressure, Low Fuel, Fast
Lap
• Programmable overrides—particularly useful for showing values such as
lap times
• Three programmable 'pages' for Warm-up, Practice and Race ensure the
driver is shown only the most relevant information at any given time
• Adjustable backlight (optional)
Software
• Windows-based software designed for setup and management of the
display and data logging system
• The user can generate a configuration file offline and send the completed
configuration to the Dash Logger
• Calculations including lap times, lap gain/loss, speed and distance, fuel
prediction
• Monitor active channels—view all channels live
• Sensor zeroing
• Details editor including event, venue and vehicle details
• Extensive Help screens
• To access the newest software features you can download the latest
version from www.motec.com/downloads
