Motorisation+ RUN24 - Page 40

EN
40
8
SBS
STEP BY STEP or SBS conguration:
0 = Normal (AP-ST-CH-ST-AP-ST…)
1 = Alternate STOP (AP-ST-CH-AP-ST-CH…)
2 = Alternate (AP-CH-AP-CH…)
3 = Apartment block – timer (N.B TCL ≠ 0)
4 = Apartment block with immediate reclosure
0 0 4
9
DLY
Second leaf delay on opening 2 0 300
10
LSI
Deceleration distance
0 to 100 = Motor deceleration percentage during
opening and closure
20 0 100 %
11
BlT
Post blackout procedure
0 = No action, remains stationery
1 = Closure
0 0 1 s
12
SBY
Energy saving: enables photocell switch-o󰀨 when
gate
is closed
0= disabled
1= enabled
0 0 1
13
nMt
Number of motors
1 = 1 motor
2 = 2 motors
2 1 2
5 - FURTHER DETAILS - ADVANCED MENU
The Advanced menu allows the system to be further customised
by modifying parameters not accessible from the basic menu.
To access the ADVANCED menu, press the MENU button and
hold it down for 5 seconds.
To modify ADVANCED MENU parameters, proceed as described
for the BASIC MENU.
N.B. Some default functions/display items may vary with respect to
the type of motor selected.
PARAMETERS DESCRIPTION DEFAULT MIN MAX UNIT
1
SP.h.
Use of PHOTO1 when starting from closed
0 = PHOTO1 is checked
1 = The gate starts even with PHOTO1 excited
1 0 1
2
Ph.2.
Use of PHOTO2
0 = Enabled during both opening and closing AP/CH
1 =Only enabled during opening AP
0 0 1
3
tP.h.
Photo-device test
0 = o󰀨
1 = PHOTO1 on
2 = PHOTO2 on
3 = PHOTO1 and PHOTO2 on
0 0 3
4
Ed.m.
STOP/EDGE input selection
0 = STOP contact (NC)
1 = Resistive safety edge (8k2)
2 = Contact safety edge (NC)
0 0 2
5
iE.D.
Sensitive edge tripping mode
0= only tripped during closure with direction reversal
1 = stops the automation (during both opening and
closure) and retreats from the obstacle
0 0 1
6
tE.D.
Edge test
0 = o󰀨
1 = on
0 0 1
7
LP.o.
Partial opening 50 0 100 %
8
TP.C.
Time for automatic closure from partial opening
(0=o󰀨)
0 0 900 s
9
FP.r.
DO NOT USE
10
tP.r.
Pre-ashing time (0 = o󰀨) 0 0 20 s
