03. CONFIGURATION 03. CONFIGURATION
The control board allows to start only one motor in order to permit pedestrian passage.
With this function, pressing the transmitter, will only open the door with the motor 1.
Programming the transmitters to pedestrian mode (CODE PED LED ON) / erase transmi
-
tter (CODE PED LED OFF):
01. Press the SEL button once until the CODE PED LED starts to flash.
02. Press the transmitter's button that you want to program during 1 second.
If you want delete transmitters, press the SET button for 1 second.
03. The CODE PED LED ON indicates that the transmitter is programmed and the CODE
PED LED OFF indicates that the transmitters have been deleted.
• CODE PED | PEDESTRIAN OPERATION
MAIN MENU MAIN MENU
Automatic operating mode (LED AUT / P-P OFF):
• The first impulse of the remote control / push-button activates the opening movement
until the end of the motor's time.
• The second impulse of the remote control / push-button activates the closing moven-
ment until the end of the motor's time.
If an order is given before the end of the motor time, the control board will perform a in-
version of movement in opening and closing.
Mode of operation step by step (LED AUT / P-P on):
• The first impulse of the remote control / push-button activates the opening movement
until the end of the motor's time.
• The second impulse of the remote control / push-button activates the closing moven
-
ment until the end of the motor's time.
If an order is given before the end of the motor time, the control board will stop the move-
ment in opening and closing. A new order will return the operation, performed in the other
direction to what it was before the stop.
The control unit is supplied by the manufacturer with the activated Automatic mode (LED
AUT / P-P off).
Note: If the T. PAUSE is active (on) and the gate is stopped during the opening maneuver,
the gate will stay stopped until the end of the pause time, and after that it will make the
• AUT/P-P | AUTOMATIC OPERATION / STEP BY STEP
The control board accepts only Dip-Switch or Rolling Code MOTORLINE transmitters, and
has a maximum capacity of 150. When trying to program the 151º transmitter, all the pro-
gramming LEDs will flash simultaneously to indicate that the memory is full.
To program new transmitters:
01. Press the SEL button as many times as necessary until the CODE LED flashes.
02. Press once the transmitter's button you want to program for 1 second.
03. The LED CODE lights up permanently, indicating the successful of the programming.
To delete all configured transmitters:
01. Press the SEL button once, and the CODE LED will begin to flash.
02. Press the SET button once. The CODE LED turns off and all transmitters have been
deleted.
If the CODE LED starts to flash quickly, means that the control board did not accept the
transmitters code, because of the following reasons:
• The transmitter is already programmed;
• The control board accepts only Rolling Code transmitters.
• CODE | TRANSMITTER PROGRAMMING
closing. If the gate is stopped during the closing maneuver, it will stop and will restart
only when receive a new order.
Select operating mode:
01. Press the SEL button once, and the AUT / P-P LED will start to flash.
02. Press the SET button for 1 second.
03. The AUT/PP LED ON means that the "step by step" mode is selected. The AUT/PP LED
OFF means that the "automatic" mode is selected.
MAIN MENU
LED LED OFF LED aceso
• AUT/P-P
Automatic Step by step
• CODE
No code Inserted code
• CODE PED.
No code Inserted code
• INB. CMD. AP
Deactivated Activated
• T. M OT.
Motor time 30 s. Programmed time
• T. MOT. PED
Motor time pedestrian 10 s. Programmed time
• T. PAUSA.
Without automatic closing
With automatic closing
• T. RIT. ANTE
No delay Programmed time
This is the main menu of the control board MC2, which has access to the most impor-
tant functions of its operation. The control board is supplied with the active main menu.
