AP-650 Series Thin Access Point: Installation Guide
4
2 Hardware Installation
2.1 Installation Instructions
The AP-650 Thin Access Point mounts either on a wall with wide-shoulder screws or on a suspended
ceiling T-bar. This unit is not designed for mounting on a desk.
To prepare for installation, perform the following steps:
1. Match the model number on the purchase order with the model numbers in the packing list
and on the case of the device shipped.
2. Verify that the contents of the box include the intended AP-650 Thin Access Point and that
the included hardware matches the package contents on page 2.
3. Review site survey and network analysis reports to determine the location and mounting
position for the AP-650 Thin Access Point.
Part Number Description
AP-0650-60010-XX 802.11a/b/g/n single radio integrated antenna configuration
AP-0650-66030-XX 802.11a/b/g/n dual radio integrated antenna configuration
AP-0650-60020-XX 802.11a/b/g/n single radio external antenna configuration
AP-0650-66040-XX 802.11a/b/g/n dual radio external antenna configuration
NOTE In the above part numbers XX represents the country code which
specifies which country the model is designed for. A country code of
“WW” represents a world wide model. A code of “OUS” represents an
outdoor US model.
NOTE The “OUS” model is approved for use outdoors and indoors operation in
the United States. Standard SKUs are approved for indoor use only.
NOTE When using WiNG 4 code, the OUS SKU must be used with WiNG 4.3.1
or a later WiNG 4.x release.
When using WiNG 5 code, the OUS SKU must be used with WiNG 5.1.0
or a later WiNG 5.x release..
