Motorola AP-650 Series User Manual

Hardware Installation
7
2.4.2 Wall Mount Procedure
1. Orient the case on the wall by its width or length.
2. Using the arrows on one edge of the case as guides, move the edge to the midline of the
mounting area and mark points on the midline for the screws
CAUTION To ensure proper operation of the AP-650 Thin Access Point ensure
that the thin access point is mounted in the correct orientation as
shown above.
Integrated Antenna Wall Mount
Correct Orientation
Incorrect Orientation
!
