Schematics, Boards Overlays, and Parts Lists: Keypad Board (APX 2000/ APX 4000 (Two Knobs)) (PC000356A02 (Model 2) / PC000356A01 (Model 3)) 8-417
PC000356A02 Keypad Board Model 2 Parts List
Ref. Des. Part Number Description
C10 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C11 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C12 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C13 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C14 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C15 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C16 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C17 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C18 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C19 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C20 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2003 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2004 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2005 NOTPLACED 64AM DUMMY PART
NUMBER
C2006 NOTPLACED 64AM DUMMY PART
NUMBER
C2008 NOTPLACED 64AM DUMMY PART
NUMBER
C2009 2113945A05 CAP,CHIP,470PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMA
C2010 2113945Y02 CAPACI-
TOR,FIXED,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG
CMIN,125DEG,CMAX,PB-
FREE
C2011 2113945Y02 CAPACI-
TOR,FIXED,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG
CMIN,125DEG,CMAX,PB-
FREE
C2012 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2018 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX
C2020 2113944A26 CAP,CHIP,12PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
Ref. Des. Part Number Description
C2022 2113944A26 CAP,CHIP,12PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C2023 2113944A26 CAP,CHIP,12PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C2050 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX
C2051 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2052 2113944A26 CAP,CHIP,12PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C21 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C22 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C23 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C24 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2414M3 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C2415M3 2113945B02 CAP,CHIP,.01UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMA
C2416M3 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
Ref. Des. Part Number Description
C2417M3 2171206F01 CAP,CER
CHIP,4.7UF,+20%,-
20%,4V-
DC,0402,X5R,MONO,SMD
,W18
C2438M3 2113945Y02 CAPACI-
TOR,FIXED,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG
CMIN,125DEG,CMAX,PB-
FREE
C2439M3 2113945Y02 CAPACI-
TOR,FIXED,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG
CMIN,125DEG,CMAX,PB-
FREE
C2440M3 2113945Y02 CAPACI-
TOR,FIXED,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG
CMIN,125DEG,CMAX,PB-
FREE
C2441M3 2113945Y02 CAPACI-
TOR,FIXED,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG
CMIN,125DEG,CMAX,PB-
FREE
C2442M3 2113945Y02 CAPACI-
TOR,FIXED,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG
CMIN,125DEG,CMAX,PB-
FREE
C2443M3 2113945Y02 CAPACI-
TOR,FIXED,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG
CMIN,125DEG,CMAX,PB-
FREE
C2444M3 2113945Y02 CAPACI-
TOR,FIXED,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG
CMIN,125DEG,CMAX,PB-
FREE
Ref. Des. Part Number Description
To Next Page
