Figure 129: Triple Antenna Relay Tray

The wiring diagram for the T2-2R with a Duplexer and Triple Relay option kit outlines the connections

for all cables and provides part numbers for each type.

MN003286A01-E

Appendix

A: Conventional GTR 8000 Base Radio Option Kits

302
