1-12 Introduction Standard Configurations
Figure 1-37. Remote Mount Configuration with High Power Transceiver,
Transceiver Interface Board and O9 Control Head
Figure 1-38. Remote Mount Configuration with Mid Power Radio Transceiver,
Universal Relay Controller and O7 Control Head (URC is optional)
(Also Applicable for O2 and O5 Control Heads)
17 ft Extension Cable
17 ft Extension Cable
O7 to URC Cable
