MN003109A01_aa
2-36 Standard Configurations Radio Mounting
2.2.3 Locking Kit (Optional) - Mid Power
2.2.3.1 All Radios
If an optional locking kit (HLN6372_) is used (shown in Figure 2-42), position the lock housing on the
trunnion after installing the radio mounting screws. Then rotate the lock with the key in it and remove
the key to lock the radio. You can install the lock on either side of the radio, and in dash and remote
mount installations.
Figure 2-42. Locking Kit (Optional)
Lock
Lock
Housing
Existing
Mounting
Screw
Draft
