Motorola ASTRO APX O9

MN003109A01_aa
Standard Configurations Radio Mounting 2-31
Figure 2-34. Multiple Control Heads Series Configurations - Mid Power
Control Head 1
Control Head 2
J300R
J300R
J200
J200
J300L
J300L
(-)
RED LEAD
(+)
BATTERY
FUSE
FUSE
FUSE
FUSE
Control Head 3
Control Head 4
J300R
J200
J200
J300L
J300R
