Motorola ASTRO APX O9

MN003109A01_aa
2-48 Standard Configurations RFID (Option)
.
Figure 2-59. Tag Angle for Mid Power Radio
.
Figure 2-60. Tag Angle for High Power Radio
Figure 2-61. Examples of Reader and Tag Aligned (Reader Orientation)
RFID Tag
Tag Angle
RFID Tag
Tag Angle
Reader
Tag
Reader
Tag
