Motorola ASTRO XTS 3000 User Manual

11-5
507 Acquisitions
Tek stopped:
T
1
Ch4
T
2
3
4
M 200us Ch1 1.5 V
W8: Transmit Audio. 1KHz Tone
which provides 3KHz deviation.
Trace 1 - IRQB @ DSP (8KHz)
Trace 2 - MODIN
Trace 3 - EXT MIC @ node C189/R198
Trace 4 - MAI @ node R207/U718
MICAMPOUT
Ch1 Freq
7.9872kHz
Low signal
amplitude
5.00V
20.0mV
MAEPF-26010-O
500mV
500mV
Ch1
Ch3
Ch2
T
T
Waveform W8
1 Acquisitions
Tek stopped:
T
1
Ch1
T
2
M1.00ms Ch1 4.52 V
W9: Power Down Reset.
Trace 1 - +5V @ U726 (VDD)
Trace 2 - Reset @ U726 (OUT)
2.00V Ch2
MAEPF-26011-O
2.00V
T
Waveform W9
