Motorola ASTRO XTS 3000 - Page 132

11-6
Wavefor m W2
493 Acquisitions
Tek stopped:
MAEPF-24385-O
T
1
Ch1
T
M 200ns Ch1 1.64 V
W10 ADSIC 2.4 MHz Reference
Trace 1 - IDC @ U406
Ch1 Freq
2.4038MHz
2.00V
Waveform W10
