Motorola ASTRO XTS 3000 User Manual

13-89
NTN8250G Vocoder Board Electrical Parts List
Notes:
1. For optimum performance, order replacement diodes, transistors, and circuit
modules by Motorola part number only.
2. When ordering crystals, specify carrier frequency, crystal frequency, crystal
type number, and Motorola part number.
3. Part value notations:
p=10
-12
n=10
-9
µ=10
-6
m=10
-3
k=10
3
M=10
6
4. ITEM refers to the component reference designator. SIDE refers to the location
of the component on the board; S1=Side 1, S2=Side 2.
5. THE NTN8250 Vocoder kits use an 8-layer printed circuit board.
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
CAPACITOR, Fixed: pF ±5%; 50V
unless otherwise stated
C401 thru C406 2113743M24 0.1 uF +80/-20% 16V
C408, C409 2113743M24 0.1 uF +80/-20% 16V
C411, C412 2113930F46 62
C413 2113932K15 0.1 uF +80/-20% 16V
C414 2113930F39 33
C415 2113930F46 62
C416 2113930F03 1 pF 50V ±0.1 pF 50V
C417 2113931F17 470
C418 2113930F03 1 pF 50V ±0.1 pF 50V
C419 2113930F20 5.1 pF 50V ±0.25 pF 50V
C420 2113743A23 0.22 uF 10%
C421 2113930F03 1 pF 50V ±0.1 pF 50V
C422 2113931F17 470
C423 2113930F34 20
C424 thru C433 2113743M24 0.1 uF +80/-20% 16V
C434 2113743A23 0.22 uF 10%
C435 thru C440 2113743M24 CAP CER .100 UF +80/-20% 16V
C441, C442 2311049A42 3.3 uF
C443 2113743M24 0.1 uF +80/-20% 16V
C446 thru C450 2113932K15 0.1 uF +80/-20% 16V
C452 2113932K15 0.1 uF +80/-20% 16V
C454 thru C456 2113932K15 0.1 uF +80/-20% 16V
C457, C458 2113931F13 330
C460 thru C464 2113743M24 0.1 uF +80/-20% 16V
DIODE: See Note 1.
CR402 4813825A06 PIN DIODE, 35V
JUMPER:
JU401 ----------------- Not Placed
JU402 0662057M01 0
COIL, RF:
L401 2462587E71 1800 nH
L402, L403 2462587Q40
PLUG:
P401 ----------------- Not Placed
PRINTED CIRCUIT BOARD:
PCB 8485725E01 Printed Circuit Board
TRANSISTOR: See Note 1.
Q1 4805128M12 NPN
RESISTOR, Fixed: Ω ±5%; 1/8W
unless otherwise stated
R401 0662057M98 10k
R402 0662057N23 100k
R403 thru R407 0662057M98 10k
R410 0662057M98 10k
R411 0662057A65 4.7k
R412, R413 0662057M98 10k
R414 0662057B12 390k
R415 0662057M74 1k
R417 0662057M88 3.9k
R418 0662057M98 10k
R419 0662057B22 1 M
R420 0662057M82 2.2k
R421 thru R424 0662057N23 100k
R425 thru R433 0662057M98 10k
INTEGRATED CIRCUIT MODULE:
See Note 1.
U401 thru U403 5185963A18 32k x 8 DSP-SRAM
U404 5185130C54 256k x 8 FLASH ROM
U405 5105457W66 DSP (Digital Signal Processor)
U406 5185963A10 ADSIC (ABACUS/DSP Support IC)
CRYSTAL: See Note 2.
Y401 4805573W01 33 MHz
LAYER 1 (L1)
LAYER 2 (L2)
LAYER 3 (L3)
LAYER 4 (L4)
INNER LAYERS
LAYER 5 (L5)
LAYER 6 (L6)
MAEPF-18828-A
SIDE 1
SIDE 2
8-LAYER CIRCUIT BOARD DETAIL VIEWING
COPPER STEPS IN PROPER LAYER SEQUENCE
LAYER 7 (L7)
LAYER 8 (L8)
