Vocoder/Controller Board Signals
Due to the nature of the schematic-generating program, signal
names must be different when they are not directly
connected
to the same point. The following tables provide a cross-
reference to the various pinouts for the same functional signal.
Vocoder Board Address Bus (A) Pinouts
Bus
U401, U402,
U403
U404 U405 U406
A0 21 20 C2/83 E9/11
A1 23 19 D3/84 E10/10
A2 24 18 D2/86 E8/8
A3 25 17 E2/87 —
A4 26 16 D4/88 —
A5 1 15 B1/92 —
A6 2 14 E3/95 —
A7 3 13 F1/96 —
A8 4 3 F2/97 —
A9 5 2 F3/98 —
A10 6 31 G1/100 —
A11 7 1 J2/101 —
A12 8 12 K1/102 —
A13 9 4 H3/104 D9/7
A14 10 5 G2/106 B9/6
A15 20 11 H2/107 D10/5
Controller Board Address Bus (HA) Pinouts
Bus U405 U701 U702 U705 U706 U727
HA0 E9/25 17 D7 10 13 21
HA1 F8/24 16 C7 9 11 20
HA2 F9/22 15 C8 8 10 19
HA3—14D87818
HA4 — 13 E6 6 2 17
HA5—12—5716
HA6 — 11 — 4 6 15
HA7—10—3514
HA8 — 9 F6 25 27 8
HA9— 8 F724127
HA10 — 7 — 21 24 36
HA11—6 —23266
HA12 — 5 — 2 4 5
HA13—4 —26284
HA14 — 3-In H8-In
H4-Out
1 3 3
HA15 — 78-In H7-In
K3-Out
——2
HA16 — — K6 — — 1
HA17——G5——40
HA18 — — J6 — — 13
HA19——H6——37
Vocoder Board Data Bus (D) Pinouts
Bus U401 U402 U403 U404 U405 U406
D0 11 — — 21 G3/110 —
D1 12 — — 22 J1/111 —
D2 13 — — 23 K3/113 —
D3 15 — — 25 L3/114 —
D4 16 — — 26 J3/116 —
D5 17 — — 27 K4/117 —
D6 18 — — 28 H4/119 —
D7 19 — — 29 L2/120 —
D8 — 11 — — K2/121 H10/21
D9—12——J4/122H9/22
D10 — 13 — — K5/126 H8/23
D11 — 15 — — L5/128 J8/26
D12 — 16 — — J5/130 L9/27
D13 — 17 — — K6/131 K8/28
D14 — 18 — — J6/133 L8/29
D15 — 19 — — H7/134 J7/30
D16 — — 11 — L9/135 K7/31
D17——12—K8/136L7/33
D18 — — 13 — K7/138 J6/34
D19——15—J7/139K6/35
D20 — — 16 — L8/141 J5/37
D21 — — 17 — K10/142 L6/38
D22 — — 18 — J9/2 L5/39
D23 — — 19 — J10/3 K5/41
Controller Board Data Bus (HD) Pinouts
Bus U405 U701 U702 U705 U706 U727
HD0 C7/44 40 C3 1 14 25
HD1 B8/43 43 B1 12 15 26
HD2 D7/41 44 C2 13 16 27
HD3 A9/39 45 D4 15 18 28
HD4 C9/38 46 C1 16 19 32
HD5C10/3547D2172033
HD6 D8/33 48 D3 18 21 34
HD7 C8/32 49 D1 19 23 35
U701 (MCU)
U701
Pin
Number
Description To/From
18 PE0 R171
19 PE4 TG1 TOGGLE SWITCH J101-34
23 PE1 B SENSE/LBAT/PWR DWN VR122
24 PE5 TG2 CONCENTRIC SWITCH J101-23
25 PE2 VOL J101-31
26 PE6 R177
27 PE3 EMERG J101-41
28 PE7 BAT_STATUS R176
P201-5
32 MOD B Q104C
33 MOD A Q104C
34 ECLK (1.8432MHz) U206-A4
35 R/W* U405-D9/30
U206-B3
36 EXTAL 7.3728MHz Y100-2
37 XTAL R158
39 4XECLK (7.3726MHz) U206-A3
50 RESET/RESET* U727-10
U206-E4
51 XIRQ* R160
52 IRQ* U206-E2
53 PG7 CSPROG* U206-E3
54 PG6 CSGEN* U708-1
55 PG5 CS101* U206-G1
56 PG4 ADSIC RST* U406-A8/97
57 PG3 ADSIC SEL* U406-B8/98
58 PG2 DSP RST* U405-G9/10
59 PG1 ROSC/PSC CE* P201-8
62 PG0 SYN SEL* P201-9
63 PD0 BOOT DATA IN (RXD) U704-2
U206-J2
64 PD1 BOOT DATA OUT (TXD)/KEYFAIL J704-1
J101-2 U717-1
65 PD2 MISO J601-7
66 PD3 MOSI J601-17 P201-17
P301-2
U406-C10/2
67 PD4 SPI SCK J601-9
P201-10
P301-1
U406-C9/1
68 PD5 DA SEL* P201-7
70 PA7 BL_HOME* J101-19
71 PA6 ECLK SHIFT Q102B
72 PA5 BOOTSTRAP* U206-E5
73 PA4 BL_FREQ J101-20
74 PA3 SB9600 BUSY J101-8
75 PA2 HREQ* U405-B10/31
76 PA1 BOOT MODE R409
77 PA0 MUX_CNTL U717-4
U702 (SLIC)
U702
Pin
Number
Description To/From
A2 MEM R/W* U705-27
U706-6
U727-9
A3 4XECLK U701-39
A4 ECLK U701-34
A5 RS232 DATA OUT/BOOT DATA IN J101-6
A7 PJ6 COL1* P107-1
B2,G3 RXDIN/RS232 DATA IN J101-4
B3 R/W* U405-D9/30
U701-35
B4 PJ0 COL3 MOB IRQ* P107-3
B6 PJ3 CTSOUT* J101-1
C4 OE* U706-1
U705-22
U727-24
C6 PJ5 OPT SEL2 J101-7
C9 POR* U726-1
D5 PJ1 COL2 P107-2
D6 PJ7 EMC EN* J601-19
E2 IRQ* J701-52
E3 AV*/CSPROG* U701-53
E4 HC11RST*/RESET* U701-50
U727-10
E5 BOOTSTRAP* U701-72
E7 BL EN P107-4
P301-4
E8 GRN LED J101-22
F2 PH2 RTA2 J101-26
F3 PH0 RTA0 J101-27
F4 PH1 RTA1 J101-24
F5 ROM2CS* U725-2
F8 ROW5 5V EN* P107-9
G1 CE*/CS101* U701-55
G2 SCNSLB R180
G4 ROW2 SPKREN* P107-6
G6 CS2B RAM SEL* U708-2
G7 ROW6 MICEN P107-10
G8 DISP EN* P301-3
G9 ROW4 TXPA EN* P107-8
H1 PH3 RTA3 J101-25
H2 PH5 INT PTT* J101-19
U206-H2
H3 PH6 EMC REQ J601-11
H9 RED LED J101-21
J2 BOOTRX/BOOT DATA IN U701-63
U704-2
J3 ROW1 P107-5
J4 EE1CS* U706-27
J7 CS1B HEN* U405-E8/28
J8 RTSIN* J101-10
J9 B+ CNTL U709-2
Q105
K2 PH7 LOCK DET* P201-3
U302-41
CR502
K5 ROM1CS* U725-1
K7 CS3B EMC WAKEUP* J601-25
K8 ROW3 BUSY OUT* P107-7
To Next Page
