Motorola CP040

3-16 VHF1 PCB 8486769Z02-A Parts List
C301 2113743L07 CAP, 390pF
C302 2113743L07 CAP, 390pF
C303 2311049A97 CAP, 33uF
C304 2113743L41 CAP, .01uF
C305 2113743N50 CAP, 100pF
C306 2113741F49 CAP, .01uF
C310 2113743L41 CAP, .01uF
C311 2113743E05 CAP, .018uF
C312 2311049A57 CAP, 10uF
C313 2113743L41 CAP, .01uF
C314 2113743L19 CAP, 1200pF
C315 2113743L19 CAP, 1200pF
C316 2113743L19 CAP, 1200pF
C320 2113743E05 CAP, .018uF
C321 2311049A57 CAP, 10uF
C322 2113743L41 CAP, .01uF
C323 2113743N54 CAP, 150pF
C331 2113743L41 CAP, .01uF
C333 2113743L41 CAP, .01uF
C334 2311049A57 CAP, 10uF
C400 Not_Placed CAP, .022uF
C401 2113743M24 CAP, 0.1uF
C402 2113743L17 CAP, 1000pF
C403 2113743N50 CAP, 100pF
C404 2113743L17 CAP, 1000pF
C405 2113743N50 CAP, 100pF
C406 2113743N50 CAP, 100pF
C407 2113743L17 CAP, 1000pF
C408 2113743L17 CAP, 1000pF
C409 2113743L17 CAP, 1000pF
C410 2311049A57 CAP, 10uF
C411 2113743M24 CAP, 0.1uF
C412 2113743L17 CAP, 1000pF
C413 2113743M24 CAP, 0.1uF
C414 2113743M24 CAP, 0.1uF
C415 2113743L17 CAP, 1000pF
C416 2113743L17 CAP, 1000pF
C417 2113743L17 CAP, 1000pF
C418 2113743M24 CAP, 0.1uF
C419 2113743L17 CAP, 1000pF
C420 2113743L41 CAP, .01uF
C421 2113743L41 CAP, .01uF
C422 2113743L41 CAP, .01uF
C425 2113743A31 CAP, 1.0uF 10% X7R
Circuit
Ref
Motorola
Part No.
Description
C426 2311049A07 CAP, 1.0uF
C430 2113743M24 CAP, 0.1uF
C431 2113743L17 CAP, 1000pF
C432 2113743M24 CAP, 0.1uF
C433 2113743L17 CAP, 1000pF
C440 2113743L41 CAP, .01uF
C441 2113743L41 CAP, .01uF
C442 2113743L41 CAP, .01uF
C443 2113743L41 CAP, .01uF
C444 2113743L41 CAP, .01uF
C445 2113743L41 CAP, .01uF
C446 2113743L41 CAP, .01uF
C447 2113743M24 CAP, 0.1uF
C451 2113743M24 CAP, 0.1uF
C452 2113743E20 CAP, 0.1uF
C453 2311049A56 CAP, 4.7uF
C454 2113743E20 CAP, 0.1uF
C455 2113743L48 CAP, .022uF
C456 2113743E20 CAP, 0.1uF
C457 2113743E20 CAP, 0.1uF
C458 2113743E20 CAP, 0.1uF
C459 2113743E20 CAP, 0.1uF
C460 2113743E20 CAP, 0.1uF
C461 2113928C04 CAP, 4.7uF
C462 2113743E20 CAP, 0.1uF
C463 2113743E20 CAP, 0.1uF
C464 2113743E20 CAP, 0.1uF
C465 2113743L17 CAP, 1000pF
C466 Not_Placed CAP, 470pF
C467 2113743L19 CAP, 1200pF
C470 2113743E20 CAP, 0.1uF
C471 2113743F18 CAP, 2.2uF
C472 2113743E20 CAP, 0.1uF
C473 2113743N54 CAP, 150pF
C474 2113743N54 CAP, 150pF
C475 2113743L48 CAP, .022uF
C476 2113743L48 CAP, .022uF
C477 2113743M24 CAP, 0.1uF
C478 2113743N54 CAP, 150pF
C479 2113743N54 CAP, 150pF
C480 2113743E20 CAP, 0.1uF
C481 Not_Placed CAP, .01uF
C482 Not_Placed CAP, .01uF
C483 2113928H02 CAP, 0.22uF
Circuit
Ref
Motorola
Part No.
Description
C484 Not_Placed CAP, .033uF
C488 2113743L09 CAP, 470pF
C489 2113743L09 CAP, 470pF
C490 2113743L09 CAP, 470pF
C492 2113928J08 CAP, 10uF
C493 2113743L17 CAP, 1000pF
C494 2113743F18 CAP, 2.2uF
C495 2113743F16 CAP, 1uF
C496 2113743F16 CAP, 1uF
C497 2113743E20 CAP, 0.1uF
C498 2113743F16 CAP, 1uF
C499 2113743N40 CAP, 39pF
C500 2113743L17 CAP, 1000pF
C501 2113743F16 CAP, 1uF
C503 2113743L17 CAP, 1000pF
C504 2113743L17 CAP, 1000pF
C505 2113743L17 CAP, 1000pF
C506 2113743L17 CAP, 1000pF
C507 2113743L17 CAP, 1000pF
C511 2113740F59 CAP, 220pF
C512 2113743N22 CAP, 6.8pF
C513 2113740F59 CAP, 220pF
C514 2113743N31 CAP, 16pF
C518 2113743E20 CAP, 0.1uF
C519 2113743F16 CAP, 1uF
CR1 4813825A19 dual Schottky, MMBD352
CR41 4802246J04 quad ring diode, HSMS2829
CR51 4813825A19 dual Schottky, MMBD352
D51 4802245J97 dual silicon DAN235ETL
D52 4802245J97 dual silicon DAN235ETL
D120 4880973Z02 silicon PIN, MA4PH261
D121 4880973Z02 silicon PIN, MA4PH261
D201 4862824C03 varactor, 1SV232
D220 4802233J09 triple diode, IMN10
D221 4802233J09 triple diode, IMN10
D251 4805649Q13 dual varactor, 1SV228
D261 4805649Q13 dual varactor, 1SV228
D262 4862824C01 varactor, 1SV229
D301 4813833A19 silicon, reverse polarity,
MBRM120ET3
D414 4805129M41 Schottky, MMBD501
D424 4809924D18 Schottky, RB520S-30
D425 4805129M41 SOT SMBD1022 RH29M19 LH
Circuit
Ref
Motorola
Part No.
Description
D440 4805729G49 dual LED red/green,
BRPY1204W
D470 4809924D18 Schottky, RB520S-30
D471 4809924D18 Schottky, RB520S-30
D491 Not_Placed Schottky, MMBD501
E451 2480640Z01 bead, BK1005HM471
E452 2480640Z01 bead, BK1005HM471
E453 2480640Z01 bead, BK1005HM471
E500 2480640Z01 bead, BK1005HM471
F301 6580542Z01 fuse, 3 amp
FL51 9186801Z01 OSC,XTAL,,44.85MHZ
FL52 9180468V04 4-pole ceramic filter, 455 kHz,
CFU455F
FL53 9180469V05 6-pole ceramic, filter, 455 kHz,
CFWC455E
FL54 9180469V03 6-pole ceramic filter, 455 kHz,
CFWC455G
J140 0986428Z01 connector, external antenna
J301 0986565Z01 battery contact assembly
J460 Not_Placed Conn_J
J470 0985818A01 connector, 2-pin internal mic
J471 0980683Z03 connector, 2.5 / 3.5mm, acces-
sories
J491 2809926G01 connector, 2-pin internal
speaker
L1 2413923C09 IDCTR, 68nH
L2 2413923C09 IDCTR, 68nH
L3 2413923C09 IDCTR, 68nH
L4 2413923C09 IDCTR, 68nH
L21 Not_Placed IDCTR, 39nH
L22 2413926N24 IDCTR, 100nH
L31 2413923C09 IDCTR, 68nH
L32 2413923C09 IDCTR, 68nH
L33 2413923C09 IDCTR, 68nH
L40 2413923C09 IDCTR, 68nH
L41 2413923C09 IDCTR, 68nH
L51 2413926N26 IDCTR, 150nH
L52 2462587V43 IDCTR, 560nH
L53 2113743N52 CAP, 120pF
L54 2413923A25 IDCTR, 1.2uH
L81 2413923A19 IDCTR, 1uH
L100 2413926K32 IDCTR, 560nH
L101 2413926K32 IDCTR, 560nH
L102 2409377M17 IDCTR, 100nH
Circuit
Ref
Motorola
Part No.
Description
