Motorola CP040

VHF1 PCB 8486769Z02-A Parts List 3-17
L103 2409377M31 IDCTR, 30nH
L110 2413926K32 IDCTR, 560nH
L120 2413926K32 IDCTR, 560nH
L121 2462587N49 IDCTR, 47nH
L130 2479990N01 IDCTR, 43.67nH
L131 2479990N01 IDCTR, 43.67nH
L132 2479990N01 IDCTR, 43.67nH
L140 2479990M01 IDCTR, 30.54nH
L211 2413926K32 IDCTR, 560nH
L251 2413926K32 IDCTR, 560nH
L252 2413926K32 IDCTR, 560nH
L253 2409377M17 IDCTR, 100nH
L254 2413923C05 IDCTR, 33nH
L255 2413926K29 IDCTR, 330nH
L262 2413926K32 IDCTR, 560nH
L263 2409377M17 IDCTR, 100nH
L264 2413923C07 IDCTR, 47nH
L265 2413926K29 IDCTR, 330nH
L270 2413926K32 IDCTR, 560nH
L271 Not_Placed IDCTR, 560nH
L276 2413926N24 IDCTR, 100nH
L281 2413926N22 IDCTR, 68nH
L282 2413926N20 IDCTR, 47nH
L283 Not_Placed IDCTR, 270nH
L291 2413926N17 IDCTR, 27nH
L292 2413926N22 IDCTR, 68nH
L471 2413926K30 IDCTR, 390nH
M140 0286427Z01 antenna nut
Q21 4802245J95 silicon NPN, BFS540
Q22 4805723X02 dFcual silicon PNP, UMT1
Q51 4802197J95 silicon NPN, PBR941
Q70 4880214G02 silicon NPN, MMBT3904
Q100 4802245J95 silicon NPN, BFS540
Q150 4880214G02 silicon NPN, MMBT3904
Q170 4809939C34 dual silicon PNP, EMB10
Q171 4880214G02 silicon NPN, MMBT3904
Q280 4802245J95 silicon NPN, BFS540
Q311 4809579E18 P-channel MOSFET, TP0101T
Q312 4809579E18 P-channel MOSFET, TP0101T
Q313 4802245J54 dual digit NPN, UMG5
Q402 4880048M01 digital NPN, DTC144EKA
Q403 4813824A17 silicon PNP, MMBT3906
Q410 4802245J54 dual digit NPN, UMG5
Circuit
Ref
Motorola
Part No.
Description
Q425 4809579E18 TSTR MOSFET P-CHAN
TP010IT
Q426 4809579E18 TSTR MOSFET P-CHAN
TP010IT
Q427 4809579E18 TSTR MOSFET P-CHAN
TP010IT
Q440 5180159R01 dual NPN, IMX1
Q470 4805723X02 dual silicon PNP, UMT1
Q471 4802245J54 dual digital NPN, UMG5
Q472 4805723X02 dual silicon PNP, UMT1
Q481 Not_Placed MMBT3906
Q482 Not_Placed MMBT3904
Q490 4802245J54 dual digital NPN, UMG5
Q493 4809579E18 P-channel MOSFET, TP0101T
Q494 4802245J54 dual digital NPN, UMG5
Q520 5180159R01 dual NPN, IMX1
R20 0662057U97 RES, 6.8K
R21 0662057M50 RES, 100
R22 0662057M94 RES, 6.8K
R23 0662057V11 RES, 22K
R24 0662057M71 RES, 750
R25 0662057M92 RES, 5.6K
R26 0662057M01 RES, 0
R40 0662057M74 RES, 1K
R51 0662057M43 RES, 51
R52 0662057N01 RES, 12K
R53 0662057N11 RES, 33K
R54 0662057M91 RES, 5.1K
R55 0662057M62 RES, 330
R57 0662057M90 RES, 4.7K
R60 0662057M83 RES, 2.4K
R61 0662057N23 RES, 100K
R62 0662057M86 RES, 3.3K
R63 0662057N13 RES, 39K
R64 0662057N06 RES, 20K
R65 0662057N13 RES, 39K
R66 0662057N06 RES, 20K
R67 0662057N06 RES, 20K
R72 0662057M64 RES, 390
R73 0662057M80 RES, 1.8K
R74 0662057M76 RES, 1.2K
R75 0662057N01 RES, 12K
R76 0662057V04 RES, 12K
R77 0662057U99 RES, 8.2K
Circuit
Ref
Motorola
Part No.
Description
R78 0662057M70 RES, 680
R80 0662057M91 RES, 5.1K
R81 0662057M74 RES, 1K
R82 Not_Placed RES, 0
R90 0662057M43 RES, 51
R91 0662057M79 RES, 1.6K
R100 0662057M61 RES, 300
R101 0662057M32 RES, 18
R102 0662057M61 RES, 300
R103 0662057M86 RES, 3.3K
R104 0662057A18 RES, 51
R105 0662057M76 RES, 1.2K
R106 0662057M90 RES, 4.7K
R107 0662057M54 RES, 150
R110 0662057M63 RES, 360
R111 Not_Placed RES, 2.7K
R120 0662057C55 RES, 150
R121 0662057C55 RES, 150
R150 0680539Z01 RES, 0.1
R151 0662057A09 RES, 22
R152 0662057V27 RES, 100K
R153 0662057V27 RES, 100K
R154 0662057V27 RES, 100K
R155 0662057V27 RES, 100K
R156 0662057M62 RES, 330
R157 0662057M92 RES, 5.6K
R158 0662057M78 RES, 1.5K
R162 0662057M98 RES, 10K
R171 0662057M94 RES, 6.8K
R202 0662057N27 RES, 150K
R205 0662057M50 RES, 100
R206 Not_Placed RES, 100
R212 0662057C01 RES, 0
R220 0662057M54 RES, 150
R221 0662057M54 RES, 150
R223 0662057M50 RES, 100
R227 0662057N27 RES, 150K
R230 0662057N24 RES, 110K
R243 0662057M80 RES, 180
R244 0662057M43 RES, 51
R245 0662057M78 RES, 1.5K
R246 0662057N23 RES, 100K
R247 0662057N28 RES, 160K
R248 0662057M43 RES, 51
Circuit
Ref
Motorola
Part No.
Description
R253 0662057M42 RES, 47
R254 0662057M58 RES, 220
R255 0662057U91 RES, 3.9K
R261 0662057N12 RES, 36K
R262 0662057M94 RES, 6.8K
R263 0662057M37 RES, 30
R264 0662057M58 RES, 220
R270 0662057M32 RES, 18
R271 0662057M96 RES, 8.2K
R272 0662057M97 RES, 9.1K
R273 0662057M61 RES, 300
R274 0662057M38 RES, 33
R275 0662057M01 RES, 0
R276 0662057M74 RES, 1K
R280 0662057M94 RES, 6.8K
R281 0662057M97 RES, 9.1K
R282 0662057M71 RES, 750
R283 0662057M56 RES, 180
R284 0662057M70 RES, 680
R286 0662057M01 RES, 0
R310 0662057N23 RES, 100K
R311 0662057N23 RES, 100K
R312 0662057N06 RES, 20K
R313 0662057M91 RES, 5.1K
R320 0662057V43 RES, 330K
R321 0662057V35 RES, 200K
R322 0662057N23 RES, 100K
R400 Not_Placed RES, 100K
R401 0662057N34 RES, 300K
R402 0662057M98 RES, 10K
R403 0662057M98 RES, 10K
R404 0662057N16 RES, 51K
R405 0662057N34 RES, 300K
R406 0662057N31 RES, 220K
R407 0662057N23 RES, 100K
R408 0662057N23 RES, 100K
R409 0662057M74 RES, 1K 5% 20X40
R410 0662057M98 RES, 10K
R411 0662057M72 RES, 820
R412 0662057N23 RES, 100K
R413 0662057N23 RES, 100K
R414 0662057N11 RES, 33K
R415 0662057N11 RES, 33K
R416 0662057N06 RES, 20K
Circuit
Ref
Motorola
Part No.
Description
