Motorola CP040

3-18 VHF1 PCB 8486769Z02-A Parts List
* Motorola Depot Servicing only
R417 0662057M98 RES, 10K
R418 0662057N23 RES, 100K
R419 0662057M90 RES, 4.7K
R420 0662057V35 RES, 200K
R421 0662057V27 RES, 100K
R422 0662057N23 RES, 100K
R423 0662057N23 RES, 100K
R424 0662057V35 RES, 200K
R425 0662057V27 RES, 100K
R430 0662057N23 RES, 100K
R431 Not_Placed RES, 100K
R432 0662057M01 RES, 0
R433 0662057N23 RES, 100K
R434 Not_Placed RES, 100K
R440 0662057M90 RES, 4.7K
R441 0662057M90 RES, 4.7K
R442 0662057A33 RES, 220
R443 0662057A27 RES, 120
R445 0662057M90 RES, 4.7K
R446 0662057M98 RES, 10K
R451 0662057N15 RES, 47K
R460 0662057N08 RES, 24K
R462 0662057N08 RES, 24K
R463 0662057N08 RES, 24K
R464 0662057N10 RES, 30K
R469 0662057M26 RES, 10
R470 0662057M82 RES, 2.2K
R471 0662057M82 RES, 2.2K
R472 0662057M70 RES, 680
R473 0662057M70 RES, 680
R474 0662057A37 RES, 330
R475 0662057N29 RES, 180K
R476 0662057N23 RES, 100K
R477 0662057M82 RES, 2.2K
R478 0662057M82 RES, 2.2K
R479 0662057N23 RES, 100K
R480 0662057B47 RES, 0
R481 Not_Placed RES, 100K
R482 Not_Placed RES, 330K
R483 Not_Placed RES, 150K
R484 Not_Placed RES, 2.2K
R485 Not_Placed RES, 100K
R486 Not_Placed RES, 100K
R487 0662057M01 RES, 0
Circuit
Ref
Motorola
Part No.
Description
R488 0662057N35 RES, 330K
R489 Not_Placed RES, 91K
R490 Not_Placed RES, 2.2K
R491 0662057M01 RES, 0
R492 0662057N08 RES, 24K
R493 0662057N35 RES, 330K
R494 0662057V43 RES, 330K
R495 0662057M92 RES, 5.6K
R496 Not_Placed RES, 10K
R497 Not_Placed RES, 1MEG
R498 Not_Placed RES, 47K
R499 Not_Placed RES, 270K
R501 0662057M50 RES, 100
R502 0662057M50 RES, 100
R503 0662057M50 RES, 100
R504 0662057M50 RES, 100
R505 0662057M50 RES, 100
R506 0662057M50 RES, 100
R507 0662057M50 RES, 100
R508 0662057N23 RES, 100K
R509 0662057N23 RES, 100K
R510 0662057N35 RES, 330K
R511 0662057N23 RES, 100K
R512 0662057N27 RES, 150K
R513 Not_Placed RES, 100K
R514 0662057N23 RES, 100K
R515 Not_Placed RES, 0
R516 Not_Placed RES, 0
R517 0662057M01 RES, 0
R518 0662057N31 RES, 220K
R519 0662057N23 RES, 100K
R520 0662057N23 RES, 100K
R521 Not_Placed RES, 100K
R522 0662057N23 RES, 100K
R523 0662057M98 RES, 10K
R524 0662057M98 RES, 10K
S440 4080710Z22 switch, rotary, 16 chan. select
4080710Z34 switch, rotary, 4 chan. select
S441 4070354A01 pushbutton switch, PTT
S442 4070354A01 pushbutton switch, side option
(lower)
S443 4070354A01 pushbutton switch, side option
(upper)
Circuit
Ref
Motorola
Part No.
Description
S444 1880619Z02 switch, rotary on-off, with 10K
volume control
SH1 2686421Z01 shield, comp side, RF front end
SH40 2686419Z01 shield, solder side, first mixer
SH50 2686423Z01 shield, solder side, IFIC and
2nd LO crystal
SH52 2686424Z01 shield, solder side, high IF
crystal filter
SH100 2686418Z01 shield, solder side, transmitter
SH200 2686424Z01 shield, solder side, synthesizer
charge pump
SH201 2686423Z01 shield, comp side, synthesizer
SH250 2686425Z01 shield, comp side, VCO tank
circuits
SH251 2686425Z01 shield, solder side, VCOBIC
SH253 2686422Z01 shield, comp side, VCO RX
injection buffer
SH400 2686420Z01 shield, solder side, micropro-
cessor
SH401 2686420Z01 shield, comp side, memory
T41 2580541Z02 transformer, balun
T42 2580541Z02 transformer, balun
U51 5186144B01 receiver system (IFIC), SA616
U52 5109522E10 triple inverter, TC7W04F
U110 0186438Z01 transmitter PA module,
RA07M1317M_VHF
U150 5113818A01 dual op amp, LM2904
U151 2484657R01 bead, 57R01
U201* 5185963A27 frequency synthesizer, 63A27
U251 5105750U54 VCO/buffer, 50U54
U310 5102478J01 5 V voltage regulator,
TK71750S
U320 5185963A55 adjustable voltage regulator w/
reset, LP2986
U330 5102479J01 3 V voltage regulator,
TK71730S
U403 Not_Placed SRM2B256
U425 5162852A09 LOW PWR OP AMP W/RAIL
TO RAIL
U451 5185130C53 audio filter (ASFIC.cmp),
30C53
U480 Not_Placed LM2904
U490 5108858K99 audio power amplifier,
TDA8541
U510 5113818A01 dual op amp, LM2904
U511 4802245J54 dual digital NPN, UMG5
Circuit
Ref
Motorola
Part No.
Description
U401* 5102226J56 microprocessor,
MC68HC11FL0
U402* 5102463J64 serial EEPROM 16Kx8,
X25128-2.7
U404* 5102480J01 Flash ROM 128Kx8,
AT49LV001N_70VI
VR110 4813830A82 zener diode, 4.3 V,
MM3Z4V3T1
VR301 4813830A33 zener diode, 20 V,
MMBZ5250B
VR302 4813830A33 zener diode, 20 V,
MMBZ5250B
VR471 4813830A18 zener diode, 6.8 V,
MMBZ5235B
VR472 4813830A09 zener diode, 3.3 V,
MMBZ5226B
VR473 4813830A33 zener diode, 20 V,
MMBZ5250B
VR474 4813830A33 zener diode, 20 V,
MMBZ5250B
VR475 4880140L20 zener diode, 15 V,
MMBZ5245B
Y51 4802245J84 crystal, 44.395 MHz
Y70 9186145B02 ceramic discriminator, 455 kHz,
45B02
Y201* 4880114R06 crystal, 16.8 MHz, 14R06
Y202 Not_Placed 45J68
Circuit
Ref
Motorola
Part No.
Description
