INTRODUCTION
Rear Panel
Before you begin installing the DCT2000 take a moment to become familiar
with the rear panel connections. The rear panel connectors are for system
cabling, and an AC power cord connects the DCT2000 to an electrical
power outlet. For cabling diagrams, see “Connecting Your DCT2000”.
