INTRODUCTION
Item Description
1
TO TV/VCR
A coaxial output to connect the DCT2000 to the TV or VCR.
2
RF IN
A coaxial input that is connected to the TO RF IN, see Connecting the DCT2000.
3
TO RF IN
A coaxial input that directs the cable signal to other connections on the DCT2000.
4
Removable plate
This plate covers the location for an optional telephone module. Available if your service provider offers
telephone communication.
5
AUX AUDIO IN
RCA audio inputs providing loop-through audio from auxiliary audio equipment.
6
COAX
A SPDIF RCA connector that provides Dolby Digital
®
audio or PCM audio. The audio settings are defined in the
electronic program guide.
7
CABLE IN
A coaxial input for the incoming signal from the wall outlet.
8
AUDIO OUT
Left/right audio outputs to connect the DCT2000 to a TV, VCR, or A/V receiver.
9
VIDEO
Composite video output to connect the DCT2000 to a TV, VCR, or A/V receiver.
10
TV Pass Card slot
This space is reserved for future use.
