INTRODUCTION
Item Description
11
Optical
connector
An optical connector that provides Dolby Digital® audio or PCM audio for connection to an A/V receiver. The
audio settings are defined in the electronics program guide.
12
DATA PORT
A data connector to interface serial data and access the high-speed serial interface from an external high
definition TV decoder (do not connect your PC to this interface).
13
S-VIDEO
An S-Video connector sending high quality video to external devices (high-end VCR or TV) that accept S-Video.
14
IR Output
An RCA output connecting the optional Infrared (IR) Blaster attachment for your DCT2000.
15
AC power
This is a two-plug AC power outlet. The bottom plug is for attaching a power cord. The top plug can be
configured for plugging in another device such as a TV or VCR.
