2-2 Test Equipment and Service Aids Service Aids
2.2 Service Aids
Table 2-2 lists the service aids recommended for working on the radio. While all of these items are
available from Motorola, most are standard workshop equipment items, and any equivalent item
capable of the same performance may be substituted for the item listed.
https://businessonline.motorolasolutions.com
Table 2-2. Service Aids
Motorola
Part No.
Description Application
RLN4460_ Portable Test Set Enables connection to the audio/accessory jack.
Allows switching for radio testing.
GMVN5141_ Customer Programming
Software on CD-ROM
Allows servicer to program radio parameters, tune
and troubleshoot radios.
PMKN4115_ Portable Programming Cable This cable connects the radio to a USB port for radio
programming and data applications.
PMKN4117_ Portable Programming, Testing &
Alignment Cable
This cable connects the radio to a USB port for radio
programming, testing and alignment.
Note: 1. This cable does not support external PTT
using Testbox.
2. This cable does not auto route to external Audio
path once the cable is attached.
3. All test instructions will require through software
tool (eg. CPS, Tuner, etc.)
PMNN4428_ 7.5V Universal Battery Eliminator Connects to radio via battery eliminator cable.
PMLN6154_ RF Adaptor Application adapts radio's antenna port to BC
cabling of test equipment.
PMLN6201_ RF Adaptor Holder Holds RF adaptor in place.
PMLN6422_ SMA RF Cable RF cable with SMA and N-type connector
1185937A01 Grease Acts to lubricate parts.
TL000013A01 Chassis and Knob Opener Separates the chassis from the front housing.
NLN9839_ Vacuum Pump Kit Allows servicer to test for leakages.
NTN4265_ Pressure Pump Kit Allows servicer to locate leakages.
5871134M01 Connector Fitting This connector allows the vacuum hose to be
connected to the radio chassis.
3271133M01 Fitting Seal This seal secures the connector fitting to the radio
chassis.
