5-50 Disassembly/Reassembly Procedures Radio Exploded Mechanical Views and Parts Lists
5.9.3 Torque Chart
Table 5-6 lists the various screws by part number and description, followed by the torque values in
different units of measure. Torque all screws to the recommended value when assembling the radio.
Table 5-6. Torque Specifications for Screws
Part Number Description
Driver/
Socket
Torque
lbs-in N-m
0385273D06 K18 Screw (Speaker Retainer)
K18 Screw (Keypad-Display Retainer)
T6 Torx
T6 Torx
2.0 to 2.2
1.5 to 1.7
0.23 to 0.25
0.17 to 0.19
03012034001 M2 Screw (Mainboard Assembly) -
New Chassis
M2 Screw (Mainboard Assembly) -
Rework Chassis
T6 Torx
T6 Torx
3.1 to 3.5
2.0
0.35 to 0.40
0.23
0316281H01 Front Kit-Back Kit Screw T6 Torx 2.1 to 2.3 0.24 to 0.26
