UHF Band 2 Circuit Board/Schematic Diagrams and Parts List (PCB 8415235H01, 8415235H05) 9-267

R201 0613952R23 CER CHIP RES 82K OHM 5%

0402

R202 0613952R25 CER CHIP RES 100K OHM

5% 0402

R204 0613952R17 CER CHIP RES 47K OHM 5%

0402

R231 0613952Q51 CER CHIP RES 120 OHM 5%

0402

R232 0613952Q68 CER CHIP RES 620 OHM 5%

0402

R233 0613952Q67 CER CHIP RES 560 OHM 5%

0402

R241 0613952Q33 CER CHIP RES 22.0 OHM

5% 0402

R242 0613952Q51 CER CHIP RES 120 OHM 5%

0402

R243 0613952R01 CER CHIP RES 10K OHM 5%

0402

R244 0613952R05 CER CHIP RES 15K OHM 5%

0402

R245 0613952Q58 CER CHIP RES 240 OHM 5%

0402

R248 0613952Q36 CER CHIP RES 30.0 OHM

5% 0402

R251 0613952Q37 CER CHIP RES 33.0 OHM

5% 0402

R252 0613952Q59 CER CHIP RES 270 OHM 5%

0402

R253 0613952Q94 CER CHIP RES 7500 OHM

5% 0402

R254 0613952Q95 CER CHIP RES 8200 OHM

5% 0402

R255 0613952Q88 CER CHIP RES 4300 OHM

5% 0402

R256 0613952Q36 CER CHIP RES 30.0 OHM

5% 0402

R260 0613952Q73 CER CHIP RES 1000 OHM

5% 0402

R281 NOT PLACED

R301 0613952R25 CER CHIP RES 100K OHM

5% 0402

R302 0613952R25 CER CHIP RES 100K OHM

5% 0402

R303 0613952Q77 CER CHIP RES 1500 OHM

5% 0402

R304 0613952R03 CER CHIP RES 12K OHM 5%

0402

R305 0613952Q65 CER CHIP RES 470 OHM 5%

0402

R306 0613952R25 CER CHIP RES 100K OHM

5% 0402

Circuit

Ref

Motorola

Part No.

Description

R307 0613952R25 CER CHIP RES 100K OHM

5% 0402

R308 0613952Q42 CER CHIP RES 51.0 OHM

5% 0402

R309 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R310 NOT PLACED

R311 0613952R13 CER CHIP RES 33K OHM 5%

0402

R312 0613952Q89 CER CHIP RES 4700 OHM

5% 0402

R313 0613952Q61 CER CHIP RES 330 OHM 5%

0402

R314 0613952Q78 CER CHIP RES 1600 OHM

5% 0402

R315 0613952R03 CER CHIP RES 12K OHM 5%

0402

R320 NOT PLACED

R321 0613952R03 CER CHIP RES 12K OHM 5%

0402

R322 0613952Q73 CER CHIP RES 1000 OHM

5% 0402

R324 0613952R27 CER CHIP RES 120K OHM

5% 0402

R328 0613952Q11 CER CHIP RES 2.7 OHM 5%

0402

R329 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R330 0613952R01 CER CHIP RES 10K OHM 5%

0402

R331 0613952Q56 CER CHIP RES 200 OHM 5%

0402

R332 0613952R03 CER CHIP RES 12K OHM 5%

0402

R333 NOT PLACED

R339 0613952Q88 CER CHIP RES 4300 OHM

5% 0402

R340 0613952Q95 CER CHIP RES 8200 OHM

5% 0402

R342 0613952R25 CER CHIP RES 100K OHM

5% 0402

R344 0613952Q42 CER CHIP RES 51.0 OHM

5% 0402

R345 0613952R15 CER CHIP RES 39K OHM 5%

0402

R346 0613952R05 CER CHIP RES 15K OHM 5%

0402

R348 0613952Q86 CER CHIP RES 3600 OHM

5% 0402

R349 0613958J74 CER CHIP RES 0.0 OHM

JMP 0805

Circuit

Ref

Motorola

Part No.

Description

R350 0613952R01 CER CHIP RES 10K OHM 5%

0402

R355 0613952R25 CER CHIP RES 100K OHM

5% 0402

R358 0613952Q73 CER CHIP RES 1000 OHM

5% 0402

R359 NOT PLACED

R360 0613952R08 CER CHIP RES 20K OHM 5%

0402

R361 0613952R08 CER CHIP RES 20K OHM 5%

0402

R363 0613952Q63 CER CHIP RES 390 OHM 5%

0402

R364 0613952Q79 CER CHIP RES 1800 OHM

5% 0402

R365 0613952Q75 CER CHIP RES 1200 OHM

5% 0402

R366 0613952R03 CER CHIP RES 12K OHM 5%

0402

R367 0613952N09 CER CHIP RES 12.1K OHM

1% 0402

R368 0613952N01 CER CHIP RES 10.0K OHM

1% 0402

R369 0613952Q69 CER CHIP RES 680 OHM 5%

0402

R370 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R371 NOT PLACED

R372 NOT PLACED

R373 NOT PLACED

R374 NOT PLACED

R375 NOT PLACED

R376 NOT PLACED

R377 NOT PLACED

R378 NOT PLACED

R400 0613952R17 CER CHIP RES 47K OHM 5%

0402

R401 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R402 NOT PLACED

R403 NOT PLACED

R405 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R406 0613952R22 CER CHIP RES 75K OHM 5%

0402

R407 0613952R21 CER CHIP RES 68K OHM 5%

0402

R408 NOT PLACED

R409 0613952R01 CER CHIP RES 10K OHM 5%

0402

Circuit

Ref

Motorola

Part No.

Description

R410 0613952R25 CER CHIP RES 100K OHM

5% 0402

R411 0613952R01 CER CHIP RES 10K OHM 5%

0402

R413 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R414 0613952P25 CER CHIP RES 178K OHM

1% 0402

R415 0613952N93 CER CHIP RES 90.9K OHM

1% 0402

R416 0613952R01 CER CHIP RES 10K OHM 5%

0402

R418 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R419 0613952Q66 CER CHIP RES 510 OHM 5%

0402

R420 0613952J73 CER CHIP RES 10.0M OHM

5% 0603

R421 0613952Q80 CER CHIP RES 2000 OHM

5% 0402

R423 0613952R41 CER CHIP RES 470K OHM

5% 0402

R424 0613952R14 CER CHIP RES 36K OHM 5%

0402

R425 0613952R12 CER CHIP RES 30K OHM 5%

0402

R426 0613952R37 CER CHIP RES 330K OHM

5% 0402

R427 0613952Q83 CER CHIP RES 2700 OHM

5% 0402

R428 0613952Q09 CER CHIP RES 2.2 OHM 5%

0402

R429 0613952R22 CER CHIP RES 75K OHM 5%

0402

R431 0613952R41 CER CHIP RES 470K OHM

5% 0402

R432 0613952R18 CER CHIP RES 51K OHM 5%

0402

R434 0613952Q61 CER CHIP RES 330 OHM 5%

0402

R435 0613952Q80 CER CHIP RES 2000 OHM

5% 0402

R436 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R437 NOT PLACED

R445 0613952R10 CER CHIP RES 24K OHM 5%

0402

R447 0613952R25 CER CHIP RES 100K OHM

5% 0402

R448 0613952R01 CER CHIP RES 10K OHM 5%

0402

Circuit

Ref

Motorola

Part No.

Description
