9-268 UHF Band 2 Circuit Board/Schematic Diagrams and Parts List (PCB 8415235H01, 8415235H05)

R449 0613952R10 CER CHIP RES 24K OHM 5%

0402

R450 0613959Y45 CER CHIP RES 68.0 OHM

5% 2512

R451 0613952R05 CER CHIP RES 15K OHM 5%

0402

R452 0613952R25 CER CHIP RES 100K OHM

5% 0402

R453 NOT PLACED

R454 NOT PLACED

R455 NOT PLACED

R456 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R457 0613952R01 CER CHIP RES 10K OHM 5%

0402

R460 0613952Q89 CER CHIP RES 4700 OHM

5% 0402

R461 0613952Q55 CER CHIP RES 180 OHM 5%

0402

R462 0613952R01 CER CHIP RES 10K OHM 5%

0402

R463 0613952Q60 CER CHIP RES 300 OHM 5%

0402

R471 0613952R08 CER CHIP RES 20K OHM 5%

0402

R472 0613952R14 CER CHIP RES 36K OHM 5%

0402

R473 0613952Q25 CER CHIP RES 10.0 OHM

5% 0402

R475 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R476 0613952R37 CER CHIP RES 330K OHM

5% 0402

R477 0613952Q73 CER CHIP RES 1000 OHM

5% 0402

R478 0613952R01 CER CHIP RES 10K OHM 5%

0402

R479 0613952Q66 CER CHIP RES 510 OHM 5%

0402

R481 0613952R10 CER CHIP RES 24K OHM 5%

0402

R492 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R498 0613952R01 CER CHIP RES 10K OHM 5%

0402

R499 0613952R01 CER CHIP RES 10K OHM 5%

0402

R501 0613952Q69 CER CHIP RES 680 OHM 5%

0402

R502 0613952Q55 CER CHIP RES 180 OHM 5%

0402

Circuit

Ref

Motorola

Part No.

Description

R505 0613952R01 CER CHIP RES 10K OHM 5%

0402

R506 0613952R17 CER CHIP RES 47K OHM 5%

0402

R507 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R601 0613952Z67 RES,MF,51KOHM,1%,.0625

W,SM,0402,200

R602 0613952Z67 RES,MF,51KOHM,1%,.0625

W,SM,0402,200

R603 0613952N12 CER CHIP RES 13.0K OHM

1% 0402

R604 0613952Z58 RES,MF,22KOHM,1%,.0625

W,SM,0402,200

R605 0613952N62 CER CHIP RES 43.2K OHM

1% 0402

R606 0613952P12 CER CHIP RES 130K OHM

1% 0402

R607 0613952N12 CER CHIP RES 13.0K OHM

1% 0402

R608 0613952Z58 RES,MF,22KOHM,1%,.0625

W,SM,0402,200

R609 0613952N62 CER CHIP RES 43.2K OHM

1% 0402

R610 0613952P12 CER CHIP RES 130K OHM

1% 0402

R611 0613952R18 CER CHIP RES 51K OHM 5%

0402

R612 0613952R43 CER CHIP RES 560K OHM

5% 0402

R613 0613952R49 CER CHIP RES 1.0M OHM

5% 0402

R614 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R617 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R618 0613952Q73 CER CHIP RES 1000 OHM

5% 0402

R619 0613952Q73 CER CHIP RES 1000 OHM

5% 0402

R620 0613952Q73 CER CHIP RES 1000 OHM

5% 0402

R621 0613952Q73 CER CHIP RES 1000 OHM

5% 0402

R622 0613952Q73 CER CHIP RES 1000 OHM

5% 0402

R623 0613952Q73 CER CHIP RES 1000 OHM

5% 0402

R626 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

Circuit

Ref

Motorola

Part No.

Description

R627 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R631 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R632 0613952R25 CER CHIP RES 100K OHM

5% 0402

R633 0613952R25 CER CHIP RES 100K OHM

5% 0402

R646 0613952R25 CER CHIP RES 100K OHM

5% 0402

R647 0613952Q84 CER CHIP RES 3000 OHM

5% 0402

R648 0613952R25 CER CHIP RES 100K OHM

5% 0402

R649 0613952R17 CER CHIP RES 47K OHM 5%

0402

RT400 0680590Z01 THERMISTOR_33K

S501 4080710Z19 SWITCH, FREQUENCY

S502 1880619Z04 VOL POTENTIOMETER with

hi temp cam

SH100 2680507Z02 SHIELD, HARMONIC FILTER

SH101 2680510Z02 SHIELD, PA

SH201 2680511Z02 SHIELD, SYNTHESIZER

SH202 2680511Z02 SHIELD, SYNTHESIZER

SH241 2604120G02 AOBA VCO SHIELD

SH242 2680514Z02 SHIELD, VCO BOTTOM/

LVZI F

SH301 2686583Z02 SHIELD, RECEIVER FRONT

END TOP

SH302 2680555Z02 SHIELD, RECEIVER F/END

BOTTOM

SH303 2680509Z02 SHIELD, MIXER

SH304 2680624Z02 SHIELD, MIXER DIODE

SH322 2686528Z01 SHIELD,RFI/EMI,CRS,TIN

SH323 2686527Z02 SHIELD, RFI/EMI, CRS, TIN

SH400 2680505Z02 SHIELD, CONTROLLER TOP

LEFT

SH401 2680506Z02 SHIELD, CONTROLLER TOP

RIGHT

SH402 2680515Z02 SHIELD, CONTROLLER

BOTTOM LEFT

SH403 2680516Z02 SHIELD, CONTROLLER BTM

RIGHT

T301 2515121H01 BALUN, TRANSFORMER

T302 2515121H01 BALUN, TRANSFORMER

U101 5115678H01 VHF/UHF/800/900 MHZ

LDMOS DRIVER IC

U102 5185765B26 IC PWR CTRL IN MOS20

U201 5115060H01 IC,FREQ SYN,AT24701-

OT4X

Circuit

Ref

Motorola

Part No.

Description

U210 5115266H01 INVERTER TC7ST04FU

SS0P5-P-A

U211 5115266H01 INVERTER TC7ST04FU

SS0P5-P-A

U241 5171121L01 CUSTOM LOW VOLTAGE

VCO BUFFER IC

U247 5115026H01 IC,LOW DROPOUT,SM,SOT-

23/6,P

U248 5115019H01 IC,LOW DROPOUT,SOT-

23,SOT-23

U301 5115281H01 FM IF IC SA616 FROM

PHILIPS

U302 5115070H01 IC,INVTR,TC7W04FU,SSOP

U303 NOT PLACED

U400 5115012H01 IC,ADJ LOW

DROPOUT,SM,POS P

U404 5115062H01 IC,CUST,TQFP48

U405 5115020H01 IC,SRAM,32K X 8,SOIC,3.6V

U406 * 5115286H01 IC 4M FLASH ROM- NON

SHRINK+EPP

U407 * 5115033H01 IC,EEPROM,16K X 8,SM

U409 5185143E03 IC,MICROP,QFP,QFP100,3.7

MHZ

U410 5115044H01 IC,LOW DROPOUT,SM,3.3V

POS

U420 5115280H01 AUDIO AMPLIFIER

TDA8547TS

U602 5115014H01 IC,COMPTR,SM,SOT-23/5

VR432 4813979P10 TRANS SUP 5.6V QUAD

VR433 4813979P10 TRANS SUP 5.6V QUAD

VR434 4815038H01 DIODE ARRAY,ZEN,

SM,SOD-323,6.93V,

VR439 4813977M21 DIODE 12V ZENER _5242_

VR440 4815038H01 DIODE ARRAY,ZEN,

SM,SOD-323,6.93V,

VR441 4815038H01 DIODE ARRAY,ZEN,S

M,SOD-323,6.93V,

VR442 4815038H01 DIODE ARRAY,ZEN,

SM,SOD-323,6.93V,

VR443 4815038H01 DIODE ARRAY,ZEN,

SM,SOD-323,6.93V,

VR444 4815038H01 DIODE ARRAY,ZEN,

SM,SOD-323,6.93V,

VR445 4813977A54 DIODE ZENER 0.2W SOD-

323 10V

VR446 4813977A54 DIODE ZENER 0.2W SOD-

323 10V

VR447 4813977A54 DIODE ZENER 0.2W SOD-

323 10V

VR448 4813977A54 DIODE ZENER 0.2W SOD-

323 10V

Circuit

Ref

Motorola

Part No.

Description
