Motorola HT Series User Manual

9-352 VHF Circuit Board/Schematic Diagrams and Parts List (PCB 8486473Z04)
C3741 NOT PLACED -
C3742 2113743L01 220pF
C3743 2113743L01 220pF
C3744 2113743L01 220pF
C3745 2113743L01 220pF
C3746 2113743L01 220pF
C3752 2113743L17 1000pF
C3753 2311049A56 4.7uF
C3754 2113928N01 0.1uF
C3755 2104993J02 2.2uF
C3761 2113743N42 47pF
C3762 2113740F63 330pF
C3763 NOT PLACED -
C3801 2113743N18 4.7pF
C3802 NOT PLACED -
C3803 2113743L17 1000pF
C3804 2113743E20 0.1uF
C3805 2113743N18 4.7pF
C3806 2113743N50 100pF
C3808 2113743N30 15pF
C3809 2113743N36 27pF
C3810 NOT PLACED -
C3811 2113928N01 0.1uF
C3812 2113928N01 0.1uF
C3813 2113743L41 10000pF
C3815 2113743L17 1000pF
C3816 2113743N22 6.8pF
C3818 2113743E07 0.022uF
C3821 2113743L41 10000pF
C3822 2113743L17 1000pF
C3823 2113743L41 10000pF
C3824 2113743N44 56pF
C3825 2113743N30 15pF
C3826 2113743N18 4.7pF
C3827 2113743E07 0.022uF
C3828 2185895Z01 0.01uF
C3829 2185895Z01 0.01uF
C383 2113743N43 51pF
Circuit
Ref
Motorola
Part No.
Description
C3830 2113743N46 68pF
C3832 2113743L17 1000pF
C3833 2113743N18 4.7pF
C3834 2113743N44 56pF
C3835 2113743N22 6.8pF
C3836 2113743N30 15pF
C3842 2113743L17 1000pF
C390 2113743N43 51pF
C400 2113743L41 10000pF
C401 2113928N01 0.1uF
C402 2113928N01 0.1uF
C4020 NOT PLACED -
C4021 NOT PLACED -
C403 2113743G24 2.2uF
C407 2113928N01 0.1uF
C408 2113743N50 100pF
C409 2113928N01 0.1uF
C410 2113928N01 0.1uF
C411 2113928N01 0.1uF
C414 2113928N01 0.1uF
C415 2185895Z01 0.01uF
C416 2113928N01 0.1uF
C419 2113743L41 10000pF
C420 2113743L41 10000pF
C421 2113928N01 0.1uF
C422 2113928N01 0.1uF
C423 2113743N50 100pF
C424 2311049A59 10uF
C425 2113928N01 0.1uF
C426 2113743N50 100pF
C427 2113743N50 100pF
C428 2113928N01 0.1uF
C429 2113928N01 0.1uF
C430 2113928N01 0.1uF
C431 2113743N50 100pF
C432 NOT PLACED -
C433 2113743L41 10000pF
C434 2113928N01 0.1uF
Circuit
Ref
Motorola
Part No.
Description
C435 2113928N01 0.1uF
C436 2113743N34 22pF
C437 2113743N34 22pF
C440 2113743G26 4.7uF
C441 2113743L09 470pF
C442 2113743E20 0.1uF
C443 2113928N01 0.1uF
C444 2113743N50 100pF
C445 2113743L09 470pF
C446 2113743L09 470pF
C447 2113928N01 0.1uF
C448 2113928N01 0.1uF
C449 2113743N50 100pF
C450 NOT PLACED -
C451 2113743M08 22000pF
C452 2113743B29 1uF
C453 2113743N50 100pF
C456 2113743N50 100pF
C458 2113743N50 100pF
C459 2113743N50 100pF
C463 2113743N50 100pF
C466 2113743N50 100pF
C467 2113928N01 0.1uF
C471 2113743L09 470pF
C472 2113743L09 470pF
C473 2113743L09 470pF
C474 2113743L41 10000pF
C475 2113743H14 10uF
C476 2113928D08 10uF
C477 2113743L17 1000pF
C478 2113743L17 1000pF
C479 2113928N01 0.1uF
C480 2113928D08 10uF
C481 2113928N01 0.1uF
C482 2113928N01 0.1uF
C483 2113743L09 470pF
C484 2113743L09 470pF
C490 2113743L09 470pF
Circuit
Ref
Motorola
Part No.
Description
C491 2113743L09 470pF
C492 2113743L09 470pF
C493 2113743N50 100pF
C494 2113743N50 100pF
C495 2113743L09 470pF
C496 2113743L09 470pF
C497 2113743L09 470pF
C498 NOT PLACED -
C502 2311049A05 0.47uF
C503 2113743N50 100pF
C505 2113743N50 100pF
C511 2113743N50 100pF
C512 2113743N50 100pF
C513 2113743N50 100pF
C514 2113743N50 100pF
C520 2113743L41 10000pF
C521 2113743L41 10000pF
C522 2113743L41 10000pF
C523 2113743L41 10000pF
C535 2113743L17 1000pF
CR3201 4813825A19 Schottky Diode
CR3202 4802245J97 Band Switching Diode
CR3203 4802245J97 Band Switching Diode
CR3301 4802245J42 Ring Quad Diode
CR3302 4805129M96 Dual Diode
CR3303 4880154K03 Dual Diode
CR411 4802245J62 Schottkt Diode
CR412 4802245J62 Schottkt Diode
CR413 4802245J62 Schottkt Diode
CR440 4813833C02 Dual Diode
CR501 4880107R01 Rectifier
CR503 4805729G49 Red / Yellow LED
D3301 4802081B58 Dual Diode
D3302 4802081B58 Dual Diode
D3521 4880973Z02 Pin Diode
D3551 4880973Z02 Pin Diode
D3701 4802233J09 Triple Diode
D3702 4802233J09 Triple Diode
Circuit
Ref
Motorola
Part No.
Description
