VHF Circuit Board/Schematic Diagrams and Parts List (PCB 8486473Z04) 9-353
D3761 4862824C03 Varactor Diode
D3821 4805649Q13 Varactor Diode
D3831 4805649Q13 Varactor Diode
D3832 4862824C01 Varactor Diode
E400 2480640Z01 Ferrite Bead
E401 2480640Z01 Ferrite Bead
E402 2480640Z01 Ferrite Bead
E403 2480640Z01 Ferrite Bead
E404 2480640Z01 Ferrite Bead
E405 2480640Z01 Ferrite Bead
E406 2480640Z01 Ferrite Bead
E407 2480640Z01 Ferrite Bead
E408 2480640Z01 Ferrite Bead
E409 2480640Z01 Ferrite Bead
F501 6580542Z01 Fuse 3A
FL401 4870368G02
Real Time Clock Xtal Oscillator
38.4kHz
H3501 2680499Z01 Heat Spreader
J3501 0985613Z01 RF Jack
J3502 0280519Z02 Antenna Nut
J400 0905505Y04 40-Pin Connector
J403 0905505Y02 20-Pin Connector
L3200 2413926K33 680nH
L3202 2413923A25 1200nH
L3203 2413926K33 680nH
L3270 2462587N68 1000nH
L3301 2462587T35 12nH
L3303 2462587T35 12nH
L3304 2462587T23 470nH
L3305 2462587T35 12nH
L3306 2462587T35 12nH
L3308 2462587T34 10nH
L3309 2462587N55 150nH
L3312 2462587V28 33nH
L3501 2413926H09 5.6nH
L3503 2462587V32 68nH
L3504 2462587N51 68nH
L3511 2462587N44 18nH
Circuit
Ref
Motorola
Part No.
Description
L3512 2479990B01 11.03nH
L3513 2479990A02 7.66nH
L3515 2479990C03 1385nH
L3518 NOT PLACED -
L3519 2484657R01 Ferrite Bead
L3521 2479990A02 7.66nH
L3522 2479990E01 23.75nH
L3523 2462587N68 1000nH
L3531 2479990N01 43.67nH
L3532 2479990N01 43.67nH
L3538 2479990M01 30.54nH
L3551 2479990N01 43.67nH
L3552 2479990A02 7.66nH
L3701 2462587Q42 390nH
L3731 2462587Q20 2200nH
L3801 2462587V34 100nH
L3809 2462587V27 27nH
L3811 2462587V34 100nH
L3812 2462587V34 100nH
L3813 2462587Q47 1000nH
L3816 2462587V34 100nH
L3821 2462587N50 56nH
L3822 2462587N49 47nH
L3823 2462587N49 47nH
L3824 2462587N68 1000nH
L3825 2462587V34 100nH
L3826 2462587N68 1000nH
L3831 2462587N50 56nH
L3832 2462587N51 68nH
L3833 2462587N50 56nH
L3834 2462587N68 1000nH
L400 2462587Q42 390nH
L401 2462587Q42 390nH
L410 2462587Q42 390nH
L411 2462587Q42 390nH
L505 2462587Q42 390nH
PB501 4086470Z01 Tactile Switch
PB502 4086470Z01 Tactile Switch
Circuit
Ref
Motorola
Part No.
Description
PB503 4086470Z01 Tactile Switch
PB504 4086470Z01 Tactile Switch
PB505 4086470Z01 Tactile Switch
Q3200 4802197J95 NPN Transistor
Q3270 4813824A10 NPN Transistor
Q3301 4880214G02 NPN Transistor
Q3302 4802197J95 NPN Transistor
Q3501 4813828A08 RF Power Amplifier
Q3561 4813824A17 PNP Transistor
Q3721 4809939C05 Dual NPN/PNP Transistor
Q3801 4802197J95 NPN Transistor
Q400 4809579E18 MOSFET P-chan Transistor
Q403 4813824A17 PNP Transistor
Q405 4802245J54 Dual NPN Transistor
Q410 4802245J54 Dual NPN Transistor
Q416 4809579E18 MOSFET P-chan Transistor
Q417 4809939C05 Dual NPN/PNP Transistor
Q502 5180159R01 Dual NPN Transistor
Q505 4880214G02 NPN Transistor
R3200 0662057M72 820
R3201 0662057M69 620
R3202 0662057N09 27K
R3203 0662057N01 12K
R3204 0662057M90 4700
R3205 0662057N06 20K
R3206 0662057M73 910
R3207 0662057N01 12K
R3208 0662057N06 20K
R3209 0662057N13 39K
R3211 0662057N13 39K
R3212 0662057N06 20K
R3213 0662057N01 12K
R3214 0662057M34 22
R3215 0662057M01 0
R3220 NOT PLACED -
R3221 0662057M43 51
R3222 0662057M70 680
R3223 0662057V04 12K
Circuit
Ref
Motorola
Part No.
Description
R3224 0662057V02 10K
R3226 0662057M64 390
R3270 0662057M74 1000
R3271 NOT PLACED -
R3273 0662057N03 15K
R3274 0662057M80 1800
R3275 0662057M76 1200
R3276 0662057N23 100K
R3301 NOT PLACED -
R3303 0662057N23 100K
R3304 0662057N23 100K
R3305 0662057N18 62K
R3306 0662057M82 2200
R3307 0662057N11 33K
R3308 0662057M78 1500
R3309 0662057M95 7500
R3310 0662057M84 2700
R3311 NOT PLACED -
R3312 0662057M19 5.1
R3313 0662057M40 39
R3314 0662057M35 24
R3315 0662057M62 330
R3316 0662057M66 470
R3317 0662057N23 100K
R3318 0662057M66 470
R3319 NOT PLACED -
R3320 NOT PLACED -
R3321 0662057M43 51
R3322 NOT PLACED -
R3323 0662057M01 0
R3324 0662057M58 220
R3501 0662057M61 300
R3502 0662057M32 18
R3503 0662057M61 300
R3505 0662057M62 330
R3506 0662057B62 3.9
R3507 0662057B62 3.9
R3512 NOT PLACED -
Circuit
Ref
Motorola
Part No.
Description
To Next Page
