VHF Circuit Board/Schematic Diagrams and Parts List (PCB 8415112H01) 9-371
VHF (136-174 MHz) Radio Parts List (PCB
8415112H01)
B501 0986237A02 CONNECTOR (CONTACT
BATTERY)
B503 3980502Z01 CONTACT, BACKUP B+
B504 3980501Z01 CONTACT, BACKUP B-
C328 2113946K02 CAP CER CHP 0.10UF 16V
C337 2113946D02 CAP CER CHP 1.0UF 6.3V
10%
C358 2113944A21 CAP CER CHP 6.8PF 50V +/-
0.5PF
C359 2113944A79 CAP,FXD,16PF,+5%,-5%,50V-
DC,0402,C
C383 2113944A85 CAP,FXD,51PF,+5%,-5%,50V-
DC,0402,C
C390 2113944A85 CAP,FXD,51PF,+5%,-5%,50V-
DC,0402,C
C400 2113945B02 CAP CER CHP 10,000PF 25V
10%
C401 2113946B04 CAP CER CHP 0.10UF 10V
10%
C402 2113946B04 CAP CER CHP 0.10UF 10V
10%
C403 2113743G24 CAP CHIP 2.2 UF 16V+80-
20%
C407 2113946B04 CAP CER CHP 0.10UF 10V
10%
C408 2113944A40 CAP CER CHP 100.0PF 50V
5%
C409 2113946B04 CAP CER CHP 0.10UF 10V
10%
C410 2113946B04 CAP CER CHP 0.10UF 10V
10%
C411 2113946B04 CAP CER CHP 0.10UF 10V
10%
C414 2113946B04 CAP CER CHP 0.10UF 10V
10%
C415 2185895Z01 CAPACITOR CER LOW DIST
.01UF
C416 2113946B04 CAP CER CHP 0.10UF 10V
10%
C419 2113945B02 CAP CER CHP 10,000PF 25V
10%
C420 2113945B02 CAP CER CHP 10,000PF 25V
10%
C421 2113946B04 CAP CER CHP 0.10UF 10V
10%
C422 2113946B04 CAP CER CHP 0.10UF 10V
10%
C423 2113944A40 CAP CER CHP 100.0PF 50V
5%
C424 NOT PLACED -
C425 2113946B04 CAP CER CHP 0.10UF 10V
10%
C426 2113944A40 CAP CER CHP 100.0PF 50V
5%
C427 2113944A40 CAP CER CHP 100.0PF 50V
5%
C428 2113946B04 CAP CER CHP 0.10UF 10V
10%
C429 2113946B04 CAP CER CHP 0.10UF 10V
10%
C430 2113946B04 CAP CER CHP 0.10UF 10V
10%
C431 2113944A40 CAP CER CHP 100.0PF 50V
5%
C432 NOT PLACED -
C433 2113945B02 CAP CER CHP 10,000PF 25V
10%
C434 2113946B04 CAP CER CHP 0.10UF 10V
10%
C435 2113946B04 CAP CER CHP 0.10UF 10V
10%
C436 2113944A29 CAP CER CHP 22.0PF 50V
5%
C437 2113944A29 CAP CER CHP 22.0PF 50V
5%
C440 2113946Q01 CAP CER CHP 4.7UF 16V
C441 2113945A05 CAP CER CHP 470PF 50V
10%
C442 2113945D04 CAP CER CHP 100,000PF
25V 10%
C443 2113946B04 CAP CER CHP 0.10UF 10V
10%
C444 2113944A40 CAP CER CHP 100.0PF 50V
5%
C445 2113945A05 CAP CER CHP 470PF 50V
10%
C446 2113945A05 CAP CER CHP 470PF 50V
10%
C447 2113946B04 CAP CER CHP 0.10UF 10V
10%
C448 2113946B04 CAP CER CHP 0.10UF 10V
10%
C449 2113944A40 CAP CER CHP 100.0PF 50V
5%
C450 NOT PLACED -
C451 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C452 2113743B29 CAP CHIP 1.00 UF 10% 16V
C453 2113944A40 CAP CER CHP 100.0PF 50V
5%
C456 2113944A40 CAP CER CHP 100.0PF 50V
5%
C458 2113944A40 CAP CER CHP 100.0PF 50V
5%
C459 2113944A40 CAP CER CHP 100.0PF 50V
5%
C463 2113944A40 CAP CER CHP 100.0PF 50V
5%
C466 2113944A40 CAP CER CHP 100.0PF 50V
5%
C467 2113946B04 CAP CER CHP 0.10UF 10V
10%
C471 2113945A05 CAP CER CHP 470PF 50V
10%
C472 2113945A05 CAP CER CHP 470PF 50V
10%
C473 2113945A05 CAP CER CHP 470PF 50V
10%
C474 2113945B02 CAP CER CHP 10,000PF 25V
10%
C475 2113743H14 CAP CHIP 10.0 UF 16V +80-
20%
C476 2113946R01 CAP CER CHP 10.0UF 10V
C477 2113945A09 CAP CER CHP 1000PF 50V
10%
C478 2113945A09 CAP CER CHP 1000PF 50V
10%
C479 2113946B04 CAP CER CHP 0.10UF 10V
10%
C480 2113946R01 CAP CER CHP 10.0UF 10V
C481 2113946B04 CAP CER CHP 0.10UF 10V
10%
C482 2113946B04 CAP CER CHP 0.10UF 10V
10%
C483 2113945A05 CAP CER CHP 470PF 50V
10%
C484 2113945A05 CAP CER CHP 470PF 50V
10%
C490 2113945A05 CAP CER CHP 470PF 50V
10%
C491 2113945A05 CAP CER CHP 470PF 50V
10%
C492 2113945A05 CAP CER CHP 470PF 50V
10%
C493 2113944A40 CAP CER CHP 100.0PF 50V
5%
C494 2113944A40 CAP CER CHP 100.0PF 50V
5%
C495 2113945A05 CAP CER CHP 470PF 50V
10%
C496 2113945A05 CAP CER CHP 470PF 50V
10%
C497 2113945A05 CAP CER CHP 470PF 50V
10%
C498 NOT PLACED -
C498 NOT PLACED -
C500 2113946B04 CAP CER CHP 0.10UF 10V
10%
C502 2313960A55 CAP TANT 0.47 UF 10% 25V
3216-18
C503 2113944A40 CAP CER CHP 100.0PF 50V
5%
C505 2113944A40 CAP CER CHP 100.0PF 50V
5%
C511 2113944A40 CAP CER CHP 100.0PF 50V
5%
C512 2113944A40 CAP CER CHP 100.0PF 50V
5%
C513 2113944A40 CAP CER CHP 100.0PF 50V
5%
C514 2113944A40 CAP CER CHP 100.0PF 50V
5%
C520 2113945B02 CAP CER CHP 10,000PF 25V
10%
C521 2113945B02 CAP CER CHP 10,000PF 25V
10%
C522 2113945B02 CAP CER CHP 10,000PF 25V
10%
C523 2113945B02 CAP CER CHP 10,000PF 25V
10%
C535 2113945A09 CAP CER CHP 1000PF 50V
10%
C610 2113944A40 CAP CER CHP 100.0PF 50V
5%
C611 2113944A40 CAP CER CHP 100.0PF 50V
5%
C612 2113944A40 CAP CER CHP 100.0PF 50V
5%
C613 2113944A40 CAP CER CHP 100.0PF 50V
5%
C615 2113944A40 CAP CER CHP 100.0PF 50V
5%
C616 2113944A40 CAP CER CHP 100.0PF 50V
5%
C618 2113944A40 CAP CER CHP 100.0PF 50V
5%
C619 2113944A40 CAP CER CHP 100.0PF 50V
5%
C620 2113944A40 CAP CER CHP 100.0PF 50V
5%
C621 2113944A40 CAP CER CHP 100.0PF 50V
5%
C622 2113944A40 CAP CER CHP 100.0PF 50V
5%
C3200 2113944A11 CAP CER CHP 2.7PF 50V +/-
0.25PF
C3201 2113944A79 CAP,FXD,16PF,+5%,-5%,50V-
DC,0402,C
C3202 NOT PLACED -
C3203 2113944A82 CAP,FXD,30PF,+5%,-5%,50V-
DC,0402,C
C3205 2113946K02 CAP CER CHP 0.10UF 16V
