Motorola HT Series User Manual

9-372 VHF Circuit Board/Schematic Diagrams and Parts List (PCB 8415112H01)
C3206 2115153H26 CAP, CERAMIC, COG
C3207 2113944A17 CAP CER CHP 4.7PF 50V +/-
0.25PF
C3208 2113946K02 CAP CER CHP 0.10UF 16V
C3209 2113946K02 CAP CER CHP 0.10UF 16V
C3210 2113946K02 CAP CER CHP 0.10UF 16V
C3212 2313960B01 CAP TANT 1.0 UF 10% 16V
3216-18
C3213 2313960B30 CAP TANT 4.7 UF 10% 10V
3216-18
C3215 2113944A25 CAP CER CHP 10.0PF 50V +/-
0.5PF
C3218 2313960B57 CAP,TANTALUM,10UF,+10%,-
10%,4V-DC,S
C3221 2113945D04 CAP CER CHP 100,000PF
25V 10%
C3222 2113946K02 CAP CER CHP 0.10UF 16V
C3225 2113946K02 CAP CER CHP 0.10UF 16V
C3226 2113946K02 CAP CER CHP 0.10UF 16V
C3228 2113946K02 CAP CER CHP 0.10UF 16V
C3230 2113946K02 CAP CER CHP 0.10UF 16V
C3231 2113946K02 CAP CER CHP 0.10UF 16V
C3232 2113946K02 CAP CER CHP 0.10UF 16V
C3233 2113946K02 CAP CER CHP 0.10UF 16V
C3234 2113946K02 CAP CER CHP 0.10UF 16V
C3236 2113945A13 CAP CER CHP 4700PF 50V
10%
C3238 2113946K02 CAP CER CHP 0.10UF 16V
C3274 2113944A82 CAP,FXD,30PF,+5%,-5%,50V-
DC,0402,C
C3275 2113944A81 CAP,FXD,24PF,+5%,-5%,50V-
DC,0402,C
C3278 2113945D04 CAP CER CHP 100,000PF
25V 10%
C3279 2113944A41 CAP CER CHP 120.0PF 50V
5%
C3301 2113944A19 CAP CER CHP 5.6PF 50V +/-
0.5PF
C3302 2113944A42 CAP CER CHP 150.0PF 50V
5%
C3303 2113944A27 CAP CER CHP 15.0PF 50V
5%
C3304 2113944A42 CAP CER CHP 150.0PF 50V
5%
C3305 NOT PLACED -
C3306 2113946B04 CAP CER CHP 0.10UF 10V
10%
C3307 2113944A40 CAP CER CHP 100.0PF 50V
5%
C3308 2113945A03 CAP CER CHP 330PF 50V
10%
C3309 2113946B04 CAP CER CHP 0.10UF 10V
10%
C3310 NOT PLACED -
C3311 2113944A42 CAP CER CHP 150.0PF 50V
5%
C3312 2113944A79 CAP,FXD,16PF,+5%,-5%,50V-
DC,0402,C
C3313 2113944A42 CAP CER CHP 150.0PF 50V
5%
C3314 NOT PLACED -
C3315 2113944A25 CAP CER CHP 10.0PF 50V +/-
0.5PF
C3316 2113944A13 CAP CER CHP 3.3PF 50V +/-
0.25PF
C3317 2113944A82 CAP,FXD,30PF,+5%,-5%,50V-
DC,0402,C
C3318 2113945B04 CAP,FXD,0.022UF,+10%,-
10%,25V-DC,04
C3319 NOT PLACED -
C3320 2113944A38 CAP CER CHP 82.0PF 50V
5%
C3321 2113945A03 CAP CER CHP 330PF 50V
10%
C3322 2113944A40 CAP CER CHP 100.0PF 50V
5%
C3323 2113944A40 CAP CER CHP 100.0PF 50V
5%
C3324 2113944A31 CAP CER CHP 33.0PF 50V
5%
C3325 2113945A09 CAP CER CHP 1000PF 50V
10%
C3326 NOT PLACED -
C3327 2113945A03 CAP CER CHP 330PF 50V
10%
C3329 2113945A03 CAP CER CHP 330PF 50V
10%
C3330 2113944A40 CAP CER CHP 100.0PF 50V
5%
C3331 2113944A40 CAP CER CHP 100.0PF 50V
5%
C3332 2113944A32 CAP CER CHP 39.0PF 50V
5%
C3334 2113944A80 CAP,FXD,20PF,+5%,-5%,50V-
DC,0402,C
C3335 2113944A29 CAP CER CHP 22.0PF 50V
5%
C3336 2313960F04 CAP TANT 33 UF 10% 16V
6032-28
C3337 2113945B04 CAP,FXD,0.022UF,+10%,-
10%,25V-DC,04
C3338 2113945A05 CAP CER CHP 470PF 50V
10%
C3339 2113944A25 CAP CER CHP 10.0PF 50V +/-
0.5PF
C3501 2113945A03 CAP CER CHP 330PF 50V
10%
C3502 2113944A31 CAP CER CHP 33.0PF 50V
5%
C3503 2113944A31 CAP CER CHP 33.0PF 50V
5%
C3504 2113945B04 CAP,FXD,0.022UF,+10%,-
10%,25V-DC,04
C3505 2113944A31 CAP CER CHP 33.0PF 50V
5%
C3508 2113945B04 CAP,FXD,0.022UF,+10%,-
10%,25V-DC,04
C3509 2113945A03 CAP CER CHP 330PF 50V
10%
C3512 2113944C38 CAP CER CHP 47.0PF 50V
5%
C3513 2113944C82 CAP,FXD,30PF,+5%,-5%,50V-
DC,0603,C
C3514 2113944C41 CAP CER CHP 68.0PF 50V
5%
C3515 2113945A12 CAP CER CHP 3300PF 50V
10%
C3516 2313960C26 CAP TANT 1.0 UF 10% 35V
3528-21
C3517 2113944C41 CAP CER CHP 68.0PF 50V
5%
C3518 NOT PLACED -
C3519 NOT PLACED -
C3521 2111078B51 CAP CHIP RF 220 5 NPO
100V
C3523 2111078B44 CAP CHIP RF 120 5 NPO
100V
C3524 2113944C80 CAP,FXD,20PF,+5%,-5%,50V-
DC,0603,C
C3525 2113944C30 CAP CER CHP 10.0PF 50V +/-
0.5PF
C3526 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C3527 NOT PLACED -
C3528 2113944C30 CAP CER CHP 10.0PF 50V +/-
0.5PF
C3531 2113944C80 CAP,FXD,20PF,+5%,-5%,50V-
DC,0603,C
C3532 2113944C41 CAP CER CHP 68.0PF 50V
5%
C3533 2113944C27 CAP CER CHP 7.5PF 50V +/-
0.5PF
C3534 2113944C22 CAP CER CHP 4.7PF 50V +/-
0.25PF
C3535 2113944C35 CAP CER CHP 27.0PF 50V
5%
C3536 2113944C32 CAP CER CHP 15.0PF 50V
5%
C3537 2113944C33 CAP CER CHP 18.0PF 50V
5%
C3539 2113944C31 CAP CER CHP 12.0PF 50V
5%
C3541 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C3542 2113945A03 CAP CER CHP 330PF 50V
10%
C3543 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C3544 2113945A03 CAP CER CHP 330PF 50V
10%
C3546 2113945A03 CAP CER CHP 330PF 50V
10%
C3547 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C3550 2113944A22 CAP CER CHP 7.5PF 50V +/-
0.5PF
C3551 2113944A36 CAP CER CHP 68.0PF 50V
5%
C3552 2113944A34 CAP CER CHP 56.0PF 50V
5%
C3560 2313960B01 CAP TANT 1.0 UF 10% 16V
3216-18
C3561 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C3562 2113945A12 CAP CER CHP 3300PF 50V
10%
C3563 2113945A12 CAP CER CHP 3300PF 50V
10%
C3564 2113945A01 CAP CER CHP 220PF 50V
10%
C3565 2113945C04 CAP CER CHP 22,000PF 50V
10%
C3566 2113944A40 CAP CER CHP 100.0PF 50V
5%
C3567 2113945A03 CAP CER CHP 330PF 50V
10%
C3568 2113945A12 CAP CER CHP 3300PF 50V
10%
C3569 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C3570 2113945A03 CAP CER CHP 330PF 50V
10%
C3571 2113945A05 CAP CER CHP 470PF 50V
10%
C3701 2113945B02 CAP CER CHP 10,000PF 25V
10%
C3702 2113945B02 CAP CER CHP 10,000PF 25V
10%
C3703 2113945B02 CAP CER CHP 10,000PF 25V
10%
C3704 2113945B02 CAP CER CHP 10,000PF 25V
10%
C3705 2113945D04 CAP CER CHP 100,000PF
25V 10%
