Motorola HT Series User Manual

VHF Circuit Board/Schematic Diagrams and Parts List (PCB 8415112H01) 9-373
C3706 2313960D05 CAP TANT 4.7 UF 10% 16V
3528-21
C3707 2113944A29 CAP CER CHP 22.0PF 50V
5%
C3708 2113946B04 CAP CER CHP 0.10UF 10V
10%
C3709 2113946B04 CAP CER CHP 0.10UF 10V
10%
C3710 2113946N03 CAP CER CHP 2.2UF 16V
C3711 2313960M51 CAP TANT 10 UF 10% 6.3V
2012-12
C3712 2113946B04 CAP CER CHP 0.10UF 10V
10%
C3713 2313960C78 CAP TANT 2.2 UF 10% 20V
3528-21
C3714 2313960D05 CAP TANT 4.7 UF 10% 16V
3528-21
C3715 2113945A05 CAP CER CHP 470PF 50V
10%
C3721 2113945D04 CAP CER CHP 100,000PF
25V 10%
C3722 2113945D04 CAP CER CHP 100,000PF
25V 10%
C3724 2313960C26 CAP TANT 1.0 UF 10% 35V
3528-21
C3725 NOT PLACED -
C3726 2113944A23 CAP CER CHP 8.2PF 50V +/-
0.5PF
C3727 2113944A40 CAP CER CHP 100.0PF 50V
5%
C3731 2113945B02 CAP CER CHP 10,000PF 25V
10%
C3732 2113945B02 CAP CER CHP 10,000PF 25V
10%
C3733 2113946N03 CAP CER CHP 2.2UF 16V
C3734 2113945B02 CAP CER CHP 10,000PF 25V
10%
C3741 NOT PLACED -
C3742 2113945A01 CAP CER CHP 220PF 50V
10%
C3743 2113945A01 CAP CER CHP 220PF 50V
10%
C3744 2113945A01 CAP CER CHP 220PF 50V
10%
C3745 2113945A01 CAP CER CHP 220PF 50V
10%
C3746 2113945A01 CAP CER CHP 220PF 50V
10%
C3752 2113945A09 CAP CER CHP 1000PF 50V
10%
C3753 2313960B30 CAP TANT 4.7 UF 10% 10V
3216-18
C3754 2113946B04 CAP CER CHP 0.10UF 10V
10%
C3755 2113946N03 CAP CER CHP 2.2UF 16V
C3761 2113944A33 CAP CER CHP 47.0PF 50V
5%
C3762 2113944C04 CAP CER CHP 330.0PF 50V
5%
C3763 NOT PLACED -
C3801 2113944A17 CAP CER CHP 4.7PF 50V +/-
0.25PF
C3802 NOT PLACED -
C3803 2113945A09 CAP CER CHP 1000PF 50V
10%
C3804 2113945D04 CAP CER CHP 100,000PF
25V 10%
C3805 2113944A17 CAP CER CHP 4.7PF 50V +/-
0.25PF
C3806 2113944A40 CAP CER CHP 100.0PF 50V
5%
C3808 2113944A27 CAP CER CHP 15.0PF 50V
5%
C3809 2113944A30 CAP CER CHP 27.0PF 50V
5%
C3810 NOT PLACED -
C3811 2113946B04 CAP CER CHP 0.10UF 10V
10%
C3812 2113946B04 CAP CER CHP 0.10UF 10V
10%
C3813 2113945B02 CAP CER CHP 10,000PF 25V
10%
C3815 2113945A09 CAP CER CHP 1000PF 50V
10%
C3816 2113944A21 CAP CER CHP 6.8PF 50V +/-
0.5PF
C3818 2113945C04 CAP CER CHP 22,000PF 50V
10%
C3821 2113945B02 CAP CER CHP 10,000PF 25V
10%
C3822 2113945A09 CAP CER CHP 1000PF 50V
10%
C3823 2113945B02 CAP CER CHP 10,000PF 25V
10%
C3824 2113944A34 CAP CER CHP 56.0PF 50V
5%
C3825 2113944A27 CAP CER CHP 15.0PF 50V
5%
C3826 2113944A17 CAP CER CHP 4.7PF 50V +/-
0.25PF
C3827 2113945C04 CAP CER CHP 22,000PF 50V
10%
C3828 2185895Z01 CAPACITOR CER LOW DIST
.01UF
C3829 2185895Z01 CAPACITOR CER LOW DIST
.01UF
C3830 2113944A36 CAP CER CHP 68.0PF 50V
5%
C3832 2113945A09 CAP CER CHP 1000PF 50V
10%
C3833 2113944A17 CAP CER CHP 4.7PF 50V +/-
0.25PF
C3834 2113944A34 CAP CER CHP 56.0PF 50V
5%
C3835 2113944A21 CAP CER CHP 6.8PF 50V +/-
0.5PF
C3836 2113944A27 CAP CER CHP 15.0PF 50V
5%
C3842 2113945A09 CAP CER CHP 1000PF 50V
10%
C4020 NOT PLACED -
C4021 NOT PLACED -
CR411 4815067H01 DIODE
ARRAY,SWG,RB731UFT108,S
MD,1M
CR412 4815067H01 DIODE
ARRAY,SWG,RB731UFT108,S
MD,1M
CR413 4815067H01 DIODE
ARRAY,SWG,RB731UFT108,S
MD,1M
CR440 4813978C02 PB FREE, NOT COMPLETELY
ENRICHED
CR501 4815155H01 RECTIFIER
CR503 4805729G49 DIODE RED/YEL
CR3201 4813974A19 DIODE SCHOTTKY BARRIER
SERIES
CR3202 4815047H01 DIODE,SWG,DAN235EFTL,35
V
CR3203 4815047H01 DIODE,SWG,DAN235EFTL,35
V
CR3301 4802245J42 RING QUAD DIODE SOT-143
PKG
CR3302 4815129H01 DIODE DUAL BONDS RH
CR3303 4815048H01 DIODE,SHTK,MMBD353LT1,S
M,7V
D104 4813978C06 DIODE DUAL 75V A2X
MMBD2836LT1
D601 4880479U01 LED
D602 4880479U01 LED
D603 4880479U01 LED
D604 4880479U01 LED
D605 4880479U01 LED
D606 4880479U01 LED
D3301 4815276H01 VARACTOR DIODE FROM
INFINEON
D3302 4815276H01 VARACTOR DIODE FROM
INFINEON
D3521 4880973Z02 PIN DIODE
D3551 4880973Z02 PIN DIODE
D3701 4815011H01 DIODE,SWG,300MA,80V
D3702 4815011H01 DIODE,SWG,300MA,80V
D3761 4815072H01 DIODE,VCTR,1SV232,30V
D3821 4885094Y01 DIODE VARACTOR ISV228
W18
D3831 4885094Y01 DIODE VARACTOR ISV228
W18
D3832 4885055Y01 DIODE VARACTOR PB-FREE
E400 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E401 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E402 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E403 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E404 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E405 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E406 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E407 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E408 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E409 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E634 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E637 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E638 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E639 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E640 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E641 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E642 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E643 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E644 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E645 2480640Z01 SURFACE MOUNT FERRITE
BEAD
F501 6515076H01 FUSE,FST BLW,3A,24V,FUSE
CHIP SMT T
FL401 4870368G02 REFLOWABLE CLOCK OSC
XTAL
H3501 2680499Z02 HEAT SPREADER
J400 0915064H03 CONNECTOR, ZIF (40 PINS)
J403 0915064H02 CONN,CONN,F,20CONT,CON
NECTOR, ZIF

Motorola HT Series Specifications

General

Battery Type	Li-Ion
Waterproof	IP54
Operating Temperature	-30°C to +60°C
Frequency Range	VHF: 136-174 MHz
Number of Channels	16
