9-374 VHF Circuit Board/Schematic Diagrams and Parts List (PCB 8415112H01)

J601 0980521Z03 CONN, ZIF VERTICAL,

40PINS

J602 0915064H01 CONN,CONN,F,18CONT,CON

NECTOR, ZIF

J3501 0985613Z01 JACK,RF

J3502 0280519Z02 NUT, ANTENNA

L400 2462587Q42 IND CHIP 390NH 10%

L401 2462587Q42 IND CHIP 390NH 10%

L410 2462587Q42 IND CHIP 390NH 10%

L411 2462587Q42 IND CHIP 390NH 10%

L505 2462587Q42 IND CHIP 390NH 10%

L3200 2414017K33 IND CER CHIP 680.0 NH 5%

L3202 2414015A25 IDCTR,CHIP,1.2UH,2%,440MA

,2OHM,CER,

L3203 2414017K33 IND CER CHIP 680.0 NH 5%

L3270 2462587N68 CHIP IND 1000 NH 5%

L3301 2415013H02 FIXED

INDUCTOR,CHIP,120NH,5%,8

50MA,

L3303 2415013H02 FIXED

INDUCTOR,CHIP,120NH,5%,8

50MA,

L3304 2462587T23 IND CHIP 470NH 5% LOW

PRO

L3305 2415013H02 FIXED

INDUCTOR,CHIP,120NH,5%,8

50MA,

L3306 2415013H02 FIXED

INDUCTOR,CHIP,120NH,5%,8

50MA,

L3308 2415013H01 FIXED

INDUCTOR,CHIP,100NH,5%,8

50MA,

L3309 2462587N55 CHIP IND 150 NH 5%

L3312 2415043H02 FIXED

INDUCTOR,RF,33NH,5%,S

L3501 2414017H09 IND CHIP 5.6 NH +/- 0.3NH

L3503 2415043H03 FIXED

INDUCTOR,RF,68NH,5%,CER

L3504 2415015H02 IDCTR,CHIP,6.8NH,5%,1A,.16

OHM,CER

L3511 2415042H01 FIXED

INDUCTOR,RF,18NH,5%,CER

L3512 2479990B01 AIR WOUND COIL/GREEN

COLOR 11.03NH

L3513 2479990A02 AIR WOUND COIL/GREEN

COLOR 7.66NH

L3515 2479990C03 AIR WOUND COIL/GREEN

COLOR 13.85NH

L3518 NOT PLACED -

L3519 2415954H01 INDUCTOR BEAD CHIP

L3521 2479990A02 AIR WOUND COIL/GREEN

COLOR 7.66NH

L3522 2.48E+07 COIL AIR WOUND/GREEN

COLOR 23.75

L3523 2462587N68 CHIP IND 1000 NH 5%

L3531 2479990N01 AIR WOUND COIL/GREEN

COLOR 43.67NH

L3532 2479990N01 AIR WOUND COIL/GREEN

COLOR 43.67NH

L3538 2479990M01 AIR WOUND COIL/GREEN

COLOR 30.54NH

L3551 2479990N01 AIR WOUND COIL/GREEN

COLOR 43.67NH

L3552 2479990A02 AIR WOUND COIL/GREEN

COLOR 7.66NH

L3701 2462587Q42 IND CHIP 390NH 10%

L3731 2462587Q20 IND CHIP 2,200NH 20%

L3801 2415043H04 IDCTR,CHIP,100NH,5%,500M

A,CER

L3809 2415043H01 FIXED

INDUCTOR,RF,27NH,5%,CER

L3811 2415043H04 IDCTR,CHIP,100NH,5%,500M

A,CER

L3812 2415043H04 IDCTR,CHIP,100NH,5%,500M

A,CER

L3813 2462587Q47 IND CHIP 1000 NH 10%

L3816 2415043H04 IDCTR,CHIP,100NH,5%,500M

A,CER

L3821 2415042H02 FIXED

INDUCTOR,RF,56NH,CER

L3822 2415015H01 IDCTR,CHIP,47NH,5%,1A,.16

OHM,CER

L3823 2415015H01 IDCTR,CHIP,47NH,5%,1A,.16

OHM,CER

L3824 2462587N68 CHIP IND 1000 NH 5%

L3825 2415043H04 IDCTR,CHIP,100NH,5%,500M

A,CER

L3826 2462587N68 CHIP IND 1000 NH 5%

L3831 2415042H02 FIXED

INDUCTOR,RF,56NH,CER

L3832 2415015H02 IDCTR,CHIP,6.8NH,5%,1A,0.1

6OHM,CER

L3833 2415042H02 FIXED

INDUCTOR,RF,56NH,CER

L3834 2462587N68 CHIP IND 1000 NH 5%

PB501 4086470Z01 TACT SWITCH

PB502 4086470Z01 TACT SWITCH

PB503 4086470Z01 TACT SWITCH

PB504 4086470Z01 TACT SWITCH

PB505 4086470Z01 TACT SWITCH

Q400 4815069H02 TSTR MOSFET P-CHAN

Q403 4813973A13 XSTR,BIP GP SS,PNP,TO-

236,SOT-23,

Q405 4815066H01 XSTR,OTHR,UMG5NFTR,250

MHZ

Q410 4815066H01 XSTR,OTHR,UMG5NFTR,250

MHZ

Q416 4815069H02 TSTR MOSFET P-CHAN

Q417 4815055H01 XSTR,GEN PURPOSE SMALL

SIG,NPN AND

Q502 4815154H01 DUAL TRANS NPN

Q505 4813973M07 TSTR NPN 40V .2A GEN

PURP

Q601 4815125H01 SOT STR RH LOW PROFILE

MMBT

Q602 4813973M07 TSTR NPN 40V .2A GEN

PURP

Q603 4813973M07 TSTR NPN 40V .2A GEN

PURP

Q3200 4802197J95 RF TRANSISTOR PBR941

Q3270 4813973M07 TSTR NPN 40V .2A GEN

PURP

Q3301 4813973M07 TSTR NPN 40V .2A GEN

PURP

Q3302 4802197J95 RF TRANSISTOR PBR941

Q3501 4813976A01 TSTR, 175 MHZ, 8W, 7.5V,

PLD 1.5

Q3561 4813973A13 XSTR,BIP GP SS,PNP,TO-

236,SOT-23,

Q3721 4815055H01 XSTR,GEN PURPOSE SMALL

SIG,NPN AND

Q3801 4802197J95 RF TRANSISTOR PBR941

R370 NOT PLACED -

R371 0613952R25 CER CHIP RES 100K OHM

5% 0402

R372 0613952R30 CER CHIP RES 160K OHM

5% 0402

R373 NOT PLACED -

R374 0613952R25 CER CHIP RES 100K OHM

5% 0402

R375 NOT PLACED -

R376 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R377 0613952R25 CER CHIP RES 100K OHM

5% 0402

R378 0613952R25 CER CHIP RES 100K OHM

5% 0402

R400 0613952R17 CER CHIP RES 47K OHM 5%

0402

R401 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R402 NOT PLACED -

R403 NOT PLACED -

R405 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R406 0613952R22 CER CHIP RES 75K OHM 5%

0402

R407 0613952R21 CER CHIP RES 68K OHM 5%

0402

R408 NOT PLACED -

R409 0613952R01 CER CHIP RES 10K OHM 5%

0402

R410 0613952R25 CER CHIP RES 100K OHM

5% 0402

R411 0613952R01 CER CHIP RES 10K OHM 5%

0402

R413 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R414 0613952P25 CER CHIP RES 178K OHM

1% 0402

R415 0613952N93 CER CHIP RES 90.9K OHM

1% 0402

R416 0613952R01 CER CHIP RES 10K OHM 5%

0402

R418 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R419 0613952Q66 CER CHIP RES 510 OHM 5%

0402

R420 0613952J73 CER CHIP RES 10.0M OHM

5% 0603

R421 0613952Q80 CER CHIP RES 2000 OHM 5%

0402

R423 0613952R23 CER CHIP RES 82K OHM 5%

0402

R424 0613952R14 CER CHIP RES 36K OHM 5%

0402

R425 0613952R12 CER CHIP RES 30K OHM 5%

0402

R426 0613952R37 CER CHIP RES 330K OHM

5% 0402

R427 0613952Q83 CER CHIP RES 2700 OHM 5%

0402

R428 0613952Q09 CER CHIP RES 2.2 OHM 5%

0402

R429 0613952R22 CER CHIP RES 75K OHM 5%

0402

R431 0613952R41 CER CHIP RES 470K OHM

5% 0402

R432 0613952R18 CER CHIP RES 51K OHM 5%

0402

R434 0613952Q61 CER CHIP RES 330 OHM 5%

0402

R435 0613952Q80 CER CHIP RES 2000 OHM 5%

0402

R436 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R437 NOT PLACED -

R445 0613952R10 CER CHIP RES 24K OHM 5%

0402

R447 0613952R25 CER CHIP RES 100K OHM

5% 0402

R448 0613952R01 CER CHIP RES 10K OHM 5%

0402
