Motorola HT Series User Manual

VHF Circuit Board/Schematic Diagrams and Parts List (PCB 8415112H01) 9-375
R449 0613952R10 CER CHIP RES 24K OHM 5%
0402
R450 0613959Y45 CER CHIP RES 68.0 OHM 5%
2512
R451 0613952R05 CER CHIP RES 15K OHM 5%
0402
R452 0613952R25 CER CHIP RES 100K OHM
5% 0402
R453 NOT PLACED -
R454 NOT PLACED -
R455 NOT PLACED -
R456 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R457 0613952R01 CER CHIP RES 10K OHM 5%
0402
R460 0613952Q89 CER CHIP RES 4700 OHM 5%
0402
R461 0613952Q55 CER CHIP RES 180 OHM 5%
0402
R462 0613952R01 CER CHIP RES 10K OHM 5%
0402
R463 0613952Q60 CER CHIP RES 300 OHM 5%
0402
R471 0613952R08 CER CHIP RES 20K OHM 5%
0402
R472 0613952Q92 CER CHIP RES 6200 OHM 5%
0402
R473 0613952Q25 CER CHIP RES 10.0 OHM 5%
0402
R475 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R476 0613952R37 CER CHIP RES 330K OHM
5% 0402
R477 0613952Q73 CER CHIP RES 1000 OHM 5%
0402
R478 0613952R01 CER CHIP RES 10K OHM 5%
0402
R479 0613952Q66 CER CHIP RES 510 OHM 5%
0402
R481 0613952R10 CER CHIP RES 24K OHM 5%
0402
R492 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R498 0613952R01 CER CHIP RES 10K OHM 5%
0402
R499 0613952R01 CER CHIP RES 10K OHM 5%
0402
R501 0613952Q69 CER CHIP RES 680 OHM 5%
0402
R502 0613952Q55 CER CHIP RES 180 OHM 5%
0402
R505 0613952R01 CER CHIP RES 10K OHM 5%
0402
R506 0613952R17 CER CHIP RES 47K OHM 5%
0402
R601 0613952Z67 RES,MF,51KOHM,1%,.0625W,
SM,0402,200
R602 0613952Z67 RES,MF,51KOHM,1%,.0625W,
SM,0402,200
R603 0613952N12 CER CHIP RES 13.0K OHM
1% 0402
R604 0613952Z58 RES,MF,22KOHM,1%,.0625W,
SM,0402,200
R605 0613952N62 CER CHIP RES 43.2K OHM
1% 0402
R606 0613952P12 CER CHIP RES 130K OHM
1% 0402
R607 0613952N12 CER CHIP RES 13.0K OHM
1% 0402
R608 0613952Z58 RES,MF,22KOHM,1%,.0625W,
SM,0402,200
R609 0613952N62 CER CHIP RES 43.2K OHM
1% 0402
R610 0613952P12 CER CHIP RES 130K OHM
1% 0402
R611 0613952R18 CER CHIP RES 51K OHM 5%
0402
R612 0613952R43 CER CHIP RES 560K OHM
5% 0402
R613 0613952R49 CER CHIP RES 1.0M OHM 5%
0402
R614 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R617 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R618 0613952Q73 CER CHIP RES 1000 OHM 5%
0402
R619 0613952Q73 CER CHIP RES 1000 OHM 5%
0402
R620 0613952Q73 CER CHIP RES 1000 OHM 5%
0402
R621 0613952Q73 CER CHIP RES 1000 OHM 5%
0402
R622 0613952Q73 CER CHIP RES 1000 OHM 5%
0402
R623 0613952Q73 CER CHIP RES 1000 OHM 5%
0402
R626 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R627 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R631 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R632 0613952R25 CER CHIP RES 100K OHM
5% 0402
R633 0613952R25 CER CHIP RES 100K OHM
5% 0402
R646 0613952R25 CER CHIP RES 100K OHM
5% 0402
R647 0613952Q84 CER CHIP RES 3000 OHM 5%
0402
R648 0613952R25 CER CHIP RES 100K OHM
5% 0402
R649 0613952R17 CER CHIP RES 47K OHM 5%
0402
R3200 0613952Q71 CER CHIP RES 820 OHM 5%
0402
R3201 0613952Q68 CER CHIP RES 620 OHM 5%
0402
R3202 0613952R11 CER CHIP RES 27K OHM 5%
0402
R3203 0613952R03 CER CHIP RES 12K OHM 5%
0402
R3204 0613952Q89 CER CHIP RES 4700 OHM 5%
0402
R3205 0613952R08 CER CHIP RES 20K OHM 5%
0402
R3206 0613952Q72 CER CHIP RES 910 OHM 5%
0402
R3207 0613952R03 CER CHIP RES 12K OHM 5%
0402
R3208 0613952R08 CER CHIP RES 20K OHM 5%
0402
R3209 0613952R15 CER CHIP RES 39K OHM 5%
0402
R3211 0613952R15 CER CHIP RES 39K OHM 5%
0402
R3212 0613952R08 CER CHIP RES 20K OHM 5%
0402
R3213 0613952R03 CER CHIP RES 12K OHM 5%
0402
R3214 0613952Q33 CER CHIP RES 22.0 OHM 5%
0402
R3215 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R3220 NOT PLACED -
R3221 0613952Q42 CER CHIP RES 51.0 OHM 5%
0402
R3222 0613952Q69 CER CHIP RES 680 OHM 5%
0402
R3223 0613952N09 CER CHIP RES 12.1K OHM
1% 0402
R3224 0613952N01 CER CHIP RES 10.0K OHM
1% 0402
R3226 0613952Q63 CER CHIP RES 390 OHM 5%
0402
R3270 0613952Q73 CER CHIP RES 1000 OHM 5%
0402
R3271 NOT PLACED -
R3273 0613952R05 CER CHIP RES 15K OHM 5%
0402
R3274 0613952Q79 CER CHIP RES 1800 OHM 5%
0402
R3275 0613952Q75 CER CHIP RES 1200 OHM 5%
0402
R3276 0613952R25 CER CHIP RES 100K OHM
5% 0402
R3301 NOT PLACED -
R3303 0613952R25 CER CHIP RES 100K OHM
5% 0402
R3304 0613952R25 CER CHIP RES 100K OHM
5% 0402
R3305 0613952R17 CER CHIP RES 47K OHM 5%
0402
R3306 0613952Q81 CER CHIP RES 2200 OHM 5%
0402
R3307 0613952R13 CER CHIP RES 33K OHM 5%
0402
R3308 0613952Q77 CER CHIP RES 1500 OHM 5%
0402
R3309 0613952Q94 CER CHIP RES 7500 OHM 5%
0402
R3310 0613952Q83 CER CHIP RES 2700 OHM 5%
0402
R3311 NOT PLACED -
R3312 0613952Q18 CER CHIP RES 5.1 OHM 5%
0402
R3313 0613952Q39 CER CHIP RES 39.0 OHM 5%
0402
R3314 0613952Q34 CER CHIP RES 24.0 OHM 5%
0402
R3315 0613952Q61 CER CHIP RES 330 OHM 5%
0402
R3316 0613952Q65 CER CHIP RES 470 OHM 5%
0402
R3317 0613952R25 CER CHIP RES 100K OHM
5% 0402
R3318 0613952Q65 CER CHIP RES 470 OHM 5%
0402
R3319 NOT PLACED -
R3320 NOT PLACED -
R3321 0613952Q42 CER CHIP RES 51.0 OHM 5%
0402
R3322 NOT PLACED -
R3323 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R3324 0613952Q57 CER CHIP RES 220 OHM 5%
0402
R3501 0613952Q60 CER CHIP RES 300 OHM 5%
0402
R3502 0613952Q31 CER CHIP RES 18.0 OHM 5%
0402
R3503 0613952Q60 CER CHIP RES 300 OHM 5%
0402
